Product Details:
|
| Name: | Photoelectric Switch | Type: | Photoelectric Switch |
|---|---|---|---|
| Category: | Elevator Parts | Business Type: | Manufacturer |
| Model: | Photoelectric Switch | Warranty Time: | 12 Months |
| Product Name: | Elevator Limit Switch | Applicable: | Elevator Equipment |
| High Light: | lift components,elevator accessories |
||
Elevator part,lift,reflective photoelectric switch/CE certificate/unique three-year warranty/infrared sensor
Reflective Photoelectric Switch Elevator Electrical Parts Infrared Sensor With CE Certificate
Infrared beam reflect
Detectable distance is 5000mm
Widely used in elevator and industrial automation field
Easy for installation
Low cost
| Parameter | |
| Voltage | DC12--24V Polariky protected |
| No-load Curren | <25mA (24V) |
| Output mode | PNP(Vcc-1.0V) or NPN(<1.0V) |
| Anti-group-pulse Interference | ±2KV |
| Light-proof | 30,000 Lux |
| Action Response Time | ≤1 ms |
| indicator Light | Light up when blocked |
| Protection Level | IP65 |
| working Temperalure | -25℃~+60℃ |
| Storage Tremperalure | -25℃~+80℃ |
| Relative Humidiky | 70%--80%RH |
| Contror Outpul | 70mA (DC24V) |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
