Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core / Traction System

Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core / Traction System

    • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System
    • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System
    • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System
    • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System
    • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System
    • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System
  • Right Hand Regular Lay Wire Ropes With Steel Core / Mixed Core /  Traction System

    Product Details:

    Place of Origin: China
    Brand Name: SUNNY
    Certification: CE,ISO9001
    Model Number: 8x19S+IWRC

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 roll
    Price: Negotiable
    Packaging Details: Wooden box
    Delivery Time: 7-15working days
    Payment Terms: Western Union, T/T, L/C,Paypal
    Supply Ability: 2000 Ton/Tons per Month
    Contact Now
    Detailed Product Description
    Name: Wire Ropes With Steel Core/Mixed Core Model: 8x19S+IWRC
    Speed: <4m/s Building Height: ≤100m
    Used: Elevator Parts Size: Na

    Wire Ropes with Steel Core/Mixed Core(IWRC/IWRF) / Traction System

    Characteristics:Preformed, bright, right hand, regular lay
    Application:Suspension ropes for elevator speed <4m/s, building height ≤100m


    Nominal rope diameterApprox.weightMinimum breaking load


    1320/1770
    1320/1620

    1370/1770

    1570/1770
    1620/1770

    157016201770
     IWRCIWRFIWRCIWRFIWRCIWRFIWRCIWRFIWRCIWRFIWRCIWRFIWRCIWRF
    mmkg/100mkNkNkNkNkNkN
    82625.934.233.635.835.23837.435.835.236.936.340.339.4
    93332.843.342.545.344.548.247.345.344.546.745.95150.2
    9.536.736.648.247.450.449.653.752.850.449.65251.256.955.9
    1040.740.553.452.555.95559.558.555.95557.756.76362
    1149.24964.663.567.666.579.170.767.666.569.868.676.275
    1258.658.376.975.680.579.185.684.280.579.18381.690.789.2
    12.765.665.386.184.790.188.695.994.390.188.69391.510299.9
    1368.868.490.288.794.592.910098.894.592.997.598.5106105
    1479.879.4105103110108117115110108113111124121
    14.383.282.8109107114112122120114112118116129127
    1591.691.1120118126124134132126124130128142139
    16104104137134143141152150143141148145161159
    17.5125124164161171168182179171168177174193190
    18132131173170181178193189181178187184204201
    19147146193190202198215211202198208205227224
    20163162214210224220238234224220231227252248
    20.6173172227223237233252248237233245241267263
    22197196258254271266288283271266279274305300




    Rope selection | Areas of application



    Rope constructionApplicationRemarks
    Class and type of coreConstruction
    6x19FC

    6x19S+SFC
    6X19W+SFC
    6X25Fi+SFC

    Governor ropes

    Recommendation:
    NFC for suspension ropes;SFC for governor ropes

    6x19S+NFC
    6X19W+NFC
    6X25Fi+NFC

    Suspension ropes for low-rise,
    low-speed elevators

    8x19FC

    8x19S+SFC
    8X19W+SFC
    8X25Fi+SFC

    Governor ropes

    8x19S+NFC
    8X19W+NFC
    8X25Fi+NFC

    Suspension ropes for elevator speed
    ≤2m/s, building height ≤60m

    Please specify when ordering if elevator speed >2m/s
    8x19 Steel core

    8x19S+8x7+1x19W
    8x19W+8x7+1x19W
    8x25Fi+8x7+1x19W

    Suspension ropes for elevator speed
    <4m/s, building height ≤100m

    Q/320205KABW02-2009

    A technical agreement
    needs to be signed for
    ordering these ropes.
    Products comply to:
    Q/320205KABM02-2009

    8x19 Mixed core

    8x19S+8x7+FC
    8x19W+8x7+FC
    8x25Fi+8x7+FC
    8x19S+5x7+FC

    Suspension ropes for elevator speed
    <4m/s, building height ≤100m

    9x19 Steel core

    9x17S+9x7+1x19W
    9x19S+9x7+1x19W
    9x19W+9x7+1x19W
    9x21Fi+9x7+1x19W
    9x25Fi+9x7+1x19W

    Suspension ropes for elevator speed
    ≥4m/s, building height >100m

    9x19 Mixed core

    9x17S+9x7+FC
    9x19S+9x7+FC
    9x19W+9x7+FC
    9x21Fi+9x7+FC
    9X25Fi+9x7+FC

    6x36 FC

    6x29Fi+FC
    6x36WS+FC

    Compensating ropes



    Ropes used by major elevator manufacturers

     ApplicationRope Construction

    Nominal rope diameter
    mm

    Nominal rope grades
    N/mm²

    Japanese
    manufacturers

    Governor ropes

    6x19S+FC
    8x19S+FC


    Φ6.0~Φ10

    1320/1770
    1620/1770
    1770

    Suspension ropes

    8x19S+FC
    8x25Fi+IWRC

    Φ8~Φ16

    1320/1770
    1620/1770

    European/
    American
    manufacturers

    Governor ropes

    6x19S+FC
    8x19S+FC

    Φ6.0~Φ10

    1370/1770
    1570/1770
    1570
    1770
    1960

    Suspension ropes

    8x19S+FC
    8x19W+FC
    8x19S+IWRC
    8x19W+IWRC
    8x25Fi+FC
    9x19S+IWRC
    9x21Fi+IWRC

    Φ8~Φ16

    1370/1770
    1570/1770
    1570
