Product Details:
|
Name: | Large Space Freight / Goods Elevator | Speed: | 0.5-1.0m/S |
---|---|---|---|
Load: | 5000kg | Model: | Goods High Speed Elevator |
Open Door Type: | Side Opening | Pit Depth: | 1500mm |
Elevator Type: | Goods Elevators | Type: | Goods High Speed Elevator |
Product: | Goods High Speed Elevator | ||
High Light: | high speed lift,airport walking escalator |
Goods High Speed Elevator Large Space Load 1000 - 5000kg 0.5 - 1.0 M/s
Our elevators adopt world-leading variable-frequency traction drive technology, the brand-new concept of integrating elevator control and drive control, permanent magnet variable frequency motor design for side opening double doors and advanced microcomputer control technology. Our goods elevators can meet the challenge of transporting freight in any environment with their considerable load-bearing power, strong structure and durability.The door is wide enough, the performance is reliable, and it is energy efficient and environmentally friendly. They are the ideal choice for such buildings and locations as cultural -, sports -, commercial - and logistics centers as well as for industry and transport.
***************************************************
For detail information, please contact us.
***************************************************
Freight elevator construction parameters
Freight elevator(≤3000kg)
Load(kg) | Open door type | Speed(m/s) | Car size(mm) | Door opening size(mm) | Machine room size(mm) | Hoistway size(mm) | Pit depth(mm) | Top floor height(mm) | Max.travelling height(m) |
CW*CD*CH | OP*OPH | HW*HD*MH | HW*HD | ||||||
1000 | side opening | 0.5 | 1500*1500*2300 | 1200*2100 | 2750*3750*2500 | 2400*2100 | 1500 | 4500 | 25 |
1.0 | 50 | ||||||||
1600 | side opening | 0.5 | 1700*2000*2300 | 1300*2100 | 3050*4250*2500 | 2700*2800 | 1500 | 4500 | 25 |
1.0 | 50 | ||||||||
2000 | side opening | 0.5 | 2000*2000*2300 | 1500*2100 | 3350*4250*2500 | 3000*2600 | 1500 | 4500 | 25 |
1.0 | 50 | ||||||||
3000 | side opening | 0.5 | 2000*2800*2300 | 1600*2100 | 2100*3400*3000 | 3100*3400 | 1500 | 4500 | 25 |
Freight elevator(≥3000kg)
Load(kg) | Open door type | Speed(m/s) | Car size(mm) | Door opening size(mm) | Machine room size(mm) | Hoistway size(mm) | Pit depth(mm) | Top floor height(mm) | Max.travelling height(m) |
CW*CD*CH | OP*OPH | HW*HD*MH | HW*HD | ||||||
5000 | Double fold | 0.25 | 2400*3700*2300 | 1600*2100 | 3600*4300*3000 | 3600*4300 | 1500 | 4500 | 12 |
0.5 | 25 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
