Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift

Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift

  • Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift
  • Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift
Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Machine Roomless Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Packaging Details: Container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Contact Now
Detailed Product Description
Name: Machine Roomless Elevator Speed: 0.5~2.0m/S
Load: 1000~5000kg Overhead: 4500mm
Pit Depth: 1500mm Warranty: 12 Months After Shipping
Elevator Type: Goods Elevators Drive Type: AC
Keywords: Passenger Elevator Lift Flooring: PVC/marble
High Light:

high speed lift

,

airport walking escalator

FUJI durable mrl elevator for goods 3000KG Freight elevator for warehouse


To move freight, you need an elevator that is designed specifically for moving freight. That means a powerful hoisting machine. Durability to cope with rough treatment. A smooth ride to handle fragile loads. Leveling accuracy for easy loading and unloading. Wide doors that maximize the usage of space in the car. .





Load Speed Car size Door size Shaft Pit depth Overhead height
kg m/s WxDxH(mm) WxH(mm) WxD(mm) P(mm) K(mm)
1000 0.5 1500x1800x2200 1200x2100 2250x2200 1500 4500
1.0 1500 4500
1.5 1600 4600
2.0 1800 4800
2000 0.5 2000x2300x2200 1500x2100 3150x2660 1500 4800
1.0 1500 5000
1.5 1600 5200
2.0 1800 5200
3000 0.5 2470x2560x2200 1800x2100 3700x3000 1600 5000
5000 0.5 2800x3400x2500 2400x2400 4250x3800 1600 6100



Machine Roomless Freight Elevator Construction Layout Drawing

Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift 0

Load 1000 - 5000kg Overhead 4500mm Warehouse Freight Elevator Lift 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
