1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor

1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor
1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor

Large Image :  1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-TM103-05
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor

Description
Name: Gearless Elevator Lift Machine Motor Load: 1350~1600kg
Speed: 1.0-2.5m/S Roping: 2:1
Weight: 550/570kg Voltage: 380V
Diameter: 440-480mm Warranty Time: 12 Months
Model: Gearless Elevator Lift Machine Motor Product: Gearless Elevator Lift Machine Motor
High Light:

2.5m/S Gearless Elevator Machine

,

480mm Gearless Elevator Machine

,

1350kg Gearless Traction Machine



Drum brake PM gearless traction machine 1350-1600kg

1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor


Large bearing capacity, suitable for large load passenger elevator, cargo elevator, hospital elevator
Motor with inter rotor structure
Using traditional drum brake, mature and reliable technology, easy adjustment and widely using


Type SN-TM103-05.4/1.0~2.5 SN-TM103-05.5/1.0~2.5
Traction ratio 2:1
Rated voltage(V) 380
Rated load(kg) 1350 1600
Max axis load(kN) 76
Self weight(kg) 550 570
Lift speed(m/s) 1 1.5 1.6/1.75 2 2.5 1 1.6/1.75 2 2.5
Traction wheel diameter(mm) 440 480 440 480
Sheave groove No 7



Elevator Traction Machine.pdf



Delivery

1350kg Diameter 480mm 2.5m/S Gearless Elevator Lift Machine Motor 0



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
