500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux

500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux

500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux
500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux
500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: FE-L
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Packaging Details: 1Pcs/Roller, 10Pcs/Carton
Delivery Time: 7~15 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 10000 Pcs/ Month
Contact Now
Detailed Product Description
Category: Elevator Parts Model Number: Elevator Light Curtain
Name: Light Curtain Elevator Transportation: Air Transportation
Business Type: Manufacturer Light Curtain: Elevator Parts
Size: 11mmx21mmx2000mm Working Distance: 0~4000mm
High Light:

500Hz Elevator Lift Light Curtain

,

Elevator Lift Light Curtain 100000Lux

,

4000mm Distance Elevator Light Curtain

Elevator Lift Center Opening Safety Light Curtain For Elevator Parts



Product Introduction

Light curtain of FE-L series elevator consists of infrared ray launcher, receiver,power pack and special connecting cable. It adopts automatically detecting technology; MCU controlling launcher and receiver start sequentially; continuously scan in the car door zone from up to down; car door system control opening or closing operation by judging whether the infrared ray is covered or not.



Main Feature

FE-L series elevator light curtain has 40 pairs of infrared tubes; scanning light beam reaches
194. The light curtain has much more sensitivity and reliability;
FE-L series elevator light curtain can automatically check the elevator door open or closed.
When the door is closed, light curtain enter dormant status which reduces energy consumption and enhances the tube life.
FE-L series elevator light curtain shortens the response time on the premise of reliability through optimized controlling methods, response time <=35ms.
FE-L series elevator light curtain has already pasted all technology testing and conforms
EN12015 EN1201 6 standard. Its light resistance is much less than 100000LUX;
FE-L series elevator light permit to shielding discontinuous multiple fault transmitters.



Technical Indicator

Horizontal tolerance ±3mm
Vertical tolerance ±10mm
Angular Displacement ±10°
Protection height 20~1840mm
Working distance 0~4000mm
Response time ≤35ms
Size 11mmx21mmx2000mm
Working condition -20℃~+65℃
Redundancy function

Permit to shielding discontinuous multiple fault transmitters

Light immunity ≤100000Lux
Shaking testing

Three axles shake at random for 4 hours, shaking
frequency is 20-500Hz,sinusoid shakes for 30 minutes.

EMC compliance

Radiation conforms EN12015,anti-interference conforms to EN12016

Power module

Input voltage220v AC土20% 4VA

Buzzer

when the light curtain is shielded for 15s, buzzer in the receiver starts buzzing
to remind passengers leaving door zone



500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux 0



500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux 1



500Hz Center Opening Safety Elevator Lift Light Curtain 100000Lux 2



FAQ

Q1: Is there free samples?

A: Yes,we could offer free sample if the unit price is less than 10usd, please contact me.

Q2: Customized logo on the elevator parts?

A: Yes,OEM and ODM are available for us.

But you should send us the Trademark authorization letter, there is min order quantity.

Q3: Get the after-service?

A: We will send you the spare parts by free if the problems caused by us.

Q4: Inspection procedures for elevator parts?

A: 100% self-inspection before packing.

Q5: Mix the 20ft container?

A: Yes,let us know your requirments please

Q6: Visit to your company before the order?

A: Sure,welcome to visit us. Our location is near by Shanghai Hongqiao airport.

Q7: By paypal and western union or cash or CNY?

A: Yes,please contact us for detail.

Q8: Delivery time of the parts?

A: Depend on the products your asked, please contact us for detail.

Q9: How to place order?

A: 1.let us know your requirment; 2 confirm the detail we will make proforma invoice for you; 3.send us payment and bankslip,or you could pay on alibaba we will release work order accordingly.4.We will send goods to you with the shipping metherd we confirmed.
