Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening

Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening

Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening
Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening
Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-DM-110A series
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5000pcs/month
Contact Now
Detailed Product Description
Name: Center Opening Permanent Magnet Synchronous Door Operator JJ: 600~1200mm
Voltage: ≤AC230V,≤DC110V Certificate: CE,CU-TR
Packing: Wooden Box Applicable: Elevator Equipment
Category: Elevator Parts Product Name: Elevator Door Operator
High Light:

Permanent Magnet Elevator Door Operator

,

Synchronous Elevator Door Operator

,

2 Leafs Elevator Door Operator

2-Leafs Center Opening Permanent Magnet Synchronous Door Operator



Serial NO: OMJ-110A (Car Top Isallation) OMJ-110C (On Car Front-Wall Isallation)
Feature:
·Using permanent magnet motor, wide torque range, high eficiency, environmental protection, energy saving
·The synchronous vane is equipped with door lock function, the door operator and landing door device 100% opened or closed synchronously
·The synchronous belt drive directly, no slip, running smoothly in lower noise
·Full-closed-loop control technology, safe, reliable and easy to adjust
·The door hanger has a safety hook to prevent ollision and fall off
·The overall structure is more compact, suitable for vlla elevator



JJ 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200
A1L 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 2400
A3L 175 200 225 250 275 300 325 350 375 400 425 450 475
B2L 890/1020 940/1070 990/1120 1040/1170 1090/1220 1140/1270 1190/1320 1240/1370 1290/1420 1340/1470 1390/1520 1440/1570 1490/1620



2-Leafs Center Opening Permanent Magnet Synchronous Door Operator (On Car Front-Wall Installation)

Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening 0

2-Leafs Center Opening Permanent Magnet Synchronous Door Operator(Car Top Installation)

Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening 1



Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening 2



Permanent Magnet Synchronous Elevator Door Operator 2 Leafs Center Opening 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
