50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System

50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System
50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System 50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System

Large Image :  50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: AC AXILAL FANS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $10~50
Packaging Details: container
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 pcs/month

50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System

Description
Name: Axial Fan Frequency: 50/60Hz
Motor: Axial Fan Type: Axial Fan
Transportation: Air Sea Express Applicable: Elevator Equipment
Temperature: -10℃ ~+60℃ Sleeve Bearing Product: Axial Fan
Voltage: 100/125V Product Name: Axial Fan
Protection: IP54
High Light:

Ball Bearings System AC Axial Fans

,

42W AC Axial Fans

,

Elevator AC Fan 60Hz

High Quality 50/60Hz 42W Power AC Axilal Fans For Ball Bearings System

Technical Parameter



Model
Bearings system



Voltage



Frequency Current Power Speed Noise Volume Phase Capacitor
V Hz A W r/min dB(A) m³/h CFM μ F
HC16050HB1-C Ball 100/125 50/60 0.32/0.3 42 2700/2800 65/68 330/380 194/223 1 3.3μ F/250V
HC16050HB2-C 200/240 50/60 0.14/0.13 42 2700/2800 65/68 330/380 194/223 1 1.0μ F/500V
HC16050HB 380/420 50/60 0.007 42 2700/2800 65/68 330/380 194/223 3 /
HC16050HB3-C 380/420 50/60 0.1 42 2700/2800 65/68 330/380 194/223 1 0.47μ F/630V


50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System 0


Technical Parameter



Model
Bearings system



Voltage



Frequency Current Power Speed Noise Volume Phase Capacitor
V Hz A W r/min dB(A) m³/h CFM μ F
HC16060HB1-C Ball 100/125 50/60 0.32/0.3 42 2700/2800 65/68 330/380 194/223 1 3.3μ F/250V
HC16060HB2-C 200/240 50/60 0.14/0.13 42 2700/2800 65/68 330/380 194/223 1 1.0μ F/500V
HC16060HB 380/420 50/60 0.007 42 2700/2800 65/68 330/380 194/223 1 /
HC16060HB3-C 380/420 50/60 0.1 42 2700/2800 65/68 330/380 194/223 1 0.47μ F/630V



50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System 1








50 / 60Hz 42W Power AC Axial Fans For Ball Bearings System 2

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
