Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque

Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque
Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque

Large Image :  Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-MVG34XL
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 5000 Pcs/ Month
Contact Now

Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque

Description
Product Name: Elevator Gearless Traction Machine Voltage: 380V
Suspension: 2:1 Load: 1000~3000KG
Weight: 750kg Max.Static Load: 3500kg
Applicable: Elevator Equipment Warranty Time: One Year
Model: Elevator Gearless Traction Machine Product: Elevator Gearless Traction Machine
Type: Elevator Gearless Traction Machine
High Light:

Elevator Gearless Traction Machine 1620

,

180s/H Gearless Traction Machine

,

Lift Elevator Gearless Traction Motor

1620 S5-40%ED 180s/H Nominal Torque Elevator Gearless Traction Machine

Static load:3500kg
Weight:750kg



Nominal Torque

Short circuited torque

Poles

Encoder
Nm Nm / /
2200
S5-40%ED
180s/h		 2650 16 ERN1387
ECN1313
EI53C9.25
TS5213N2531
Brake
 RTW2000[2x2000nM] 2x178W-207V



    Ropes Dimensions
ØD F Ø n° Pitch A
mm mm mm n° mm mm
440 180 11 10 17 177.5
480 180 12 8 20 177.5
520 180 13 8 20 177.5


Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque 0



Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque 1




Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque 2

Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque 3

Elevator Gearless Traction Machine 1620 S5-40%ED 180s/H Nominal Torque 4

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
