Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg
Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg

Large Image :  Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-PMG140A
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 5000 Pcs/ Month
Contact Now

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg

Description
Product Name: Elevator Gearless Traction Machine Voltage: 380Vor220V
Suspension: 1:1 Load: 1000kg
Weight: 280kg Max.Static Load: 1200kg
Applicable: Elevator Equipment Warranty Time: One Year
Model: Gearless Traction Machine Product: Gearless Traction Machine
Type: Gearless Traction Machine
High Light:

1200kg Elevator Gearless Traction Machine

,

Passenger Lift Traction Gearless Motor

,

220V Gearless Traction Elevator Motor

Max.Static Load 1200kg Ratio 49:2 Elevator Gearless Traction Machine



Type:SN-PMG140A


ELEVATOR TRACTION MACHINE

Suspension

1:1

Voltage

380Vor220V

Pole

8

Rating

S5(25%)

INS. Class

F

IP Code

IP41

FZD15 Brake

DC110V 1.04A

Max. Static Load

1200kg

Weight

280kg



DIMENSIONS

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg 0




TECHNICAL DATA

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg 1


REMARK

1.As shown is right sheave type (equipped with right-handed rotation drum wheel) , left sheave type is optional(equipped with lift-handed rotation drum wheel) .



Type:SN-PMG140A


ELEVATOR TRACTION MACHINE

Suspension

1:1

Voltage

380Vor220V

Pole

8

Rating

S5(25%)

INS. Class

F

IP Code

IP41

FZD15 Brake

DC110V 1.04A

Max. Static Load

1200kg

Weight

280kg



DIMENSIONS

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg 2



TECHNICAL DATA
Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg 3

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg 4

Ratio 49:2 Elevator Gearless Traction Machine Max.Static Load 1200kg 5

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
