Product Details:
|
| Name: | Freight Elevator Lift | Load: | 1000-10000kg |
|---|---|---|---|
| Speed: | 0.5-1.75m/S | Application: | Shopping Malls, Hotel, Factory, Warehouse, Airport |
| Traction Ratio: | 2:1, 4:1 | Construction Type: | Machine Room And Machine Roomless |
| Product Name: | Passenger Lift | Traction Machine: | Gearless Traction Machine |
| Model: | Freight Elevator Lift | Product: | Freight Elevator Lift |
| High Light: | high speed lift,airport walking escalator |
||
Stable Load 1000-10000kg Freight Elevator , High Speed Lift For Warehouse / Factory
| Freight Elevator Series Freight Elevator |
| Adopt roping 4:1 with or without mini machine room, and it's the newest technology for freight elevator in the market, which can be more energy-saving and space saving. |
| The capacity is from 1000kg to 10000kg, and speed is from 0.5m/s to 1.75m/s. |
| The traction system is equipped with VVVF vector control to make the start, acceleration, deceleration and stop of elevator in stable and comfortable. |
| 0-speedbraking stop is used to greatly increase the leveling accuracy, reduce the noise and vibration of operation and save energy over 30% than traditional AC double-speed traction. |
4:1 Freight elevator parameters
| Capacity (kg) | Speed (m/s) | Cabin size (mm) | Shaft size (mm) | Door size (mm) | Overhead (mm) | Pit (mm) | Rated power (kw) |
| 2000 | 0.5/0.75/1.0 | 1900*2100*2200 | 2900*2700 | 1600*2100 | 4300 | 1500 | 6.6/11.6/13.6 |
| 3000 | 0.5/0.75/1.0 | 2200*2500*2200 | 3300*3200 | 1700*2100 | 4300 | 1600 | 11.1/19.4/22.2 |
| 5000 | 0.5/0.75/1.0 | 2800*3100*2200 | 4200*3800 | 2400*2100 | 4500 | 1800 | 17/27.2/37 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
