Construction 120m/Min Speed High Speed Elevator Construction Lift

Construction 120m/Min Speed High Speed Elevator Construction Lift
Construction 120m/Min Speed High Speed Elevator Construction Lift Construction 120m/Min Speed High Speed Elevator Construction Lift

Large Image :  Construction 120m/Min Speed High Speed Elevator Construction Lift

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Construction Lift
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: $5000~8000
Packaging Details: wooden case
Delivery Time: 7-15working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 500 Set/ Year

Construction 120m/Min Speed High Speed Elevator Construction Lift

Description
Name: Construction Lift Load: 1600/2000kg
Speed: 120m/min Door Opening: 1100*2200mm
Travelling Height: ≤200m Warranty: 12 Months After Shipping
Model: Construction Lift Product: Construction Lift
Highlight:

high speed lift

,

building lifts elevators

Construction 120m/Min Speed High Speed Elevator Construction Lift

Construction 120m/Min Speed High Speed Elevator



Advantage Description: Safety
The equipment runs in the elevator shaft and is surrounded by solid shaft walls , which fundamentally eliminates the possibility of car tilting.
When the car runs to the top, the counter-weight reaches the pit bottom, and the steel rope will slack and slip on the traction sheave, which completely eradicate the possibility of car hitting ceiling in theory.
The adoption of “speed governor + safety gear" ensures that the car will not stall and fall. This design is 100% reliable .



Main Parameter

Main Parameter
Figure
Unit
Load
1600/2000
kg
Speed
120
m/min
Door Opening Size

1100*2200
mm
Car Size
Width
1700~2200
mm
Depth
1600~2100
mm
Heigh
3000
mm
Shaft Dimension
Width
2100~2700
mm
Depth
2100~2700
mm
Travelling Height
≤200
m



Construction 120m/Min Speed High Speed Elevator Construction Lift 0



Construction 120m/Min Speed High Speed Elevator Construction Lift 1Construction 120m/Min Speed High Speed Elevator Construction Lift 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
