Large Image :  Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-LCD-043002
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $10~30
Packaging Details: 25Pcs/Carton
Delivery Time: 10 working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 1000 Pcs/ Month

Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift

Description
Name: Elevator LCD Display Type: Elevator Parts
Visible Size(mm): 129x94 Powe: 1.2W
Display: 4.3’ Voltage: DC 16V-DC 24V
Product Name: Elevator LCD Display Category: Elevator Parts
Model: Elevator LCD Display
Highlight:

lift lcd display

,

elevator part

LCD Elevator Display with SN-LCD-043002

Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift



Parameter
Display Size 4.3’
Visible Size(mm) 129x94
Input Signal Parallel System: Binary Code, Decimal Code, BCD Code, Gray Code, 7 Segment Code; Serial System: Canbus, Rs48S, Modbus
Display Tech Blue background and white words, Black background and yellow words, customized color available
Voltage DC 16V-DC 24V
Power 1.2W
Working/Storage Temp Temperature:-10℃~50℃, Humidity:20%~90% / Temperature:-20℃~60℃, Humidity:10%~90%
Content Floor 1-99, A-Z Letter, Direction, Overload, Fire, Maintenance and Date,time
Customized Function Customized Logo and words







Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift 0

Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift 1



Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift 2Custom Elevator LCD Display Digital Lcd Display Lcd Monitor For Lift 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
