|Name:||Automatic Moving Walks||Conveyor Length:||10000-70000mm|
|Dip Angle α:||0-6°||Speed V:||0.5m/s|
|Usage:||Subway/Airport /Shopping Mall Moving Walk||Step Material:||Stainless Steel|
airport walking escalator,
airport moving walkway
Superior performance of moving walk
·Compact structure, ease strain: Short pallets can greatly reduce span span, which can fiexibly fits the building structure and save the construction space for the customer, it comprises H version (horizontal). I version (incline) and c version (compact) which can let the customer have a free choice on his original layout.
·Conform to quality/safety standard: Slip-free grooves on pallet surface have an excellent slip-proof function which makes the ride save and comfortable. Slightly inclined combs can make trolleys easily get on an doff. SUNNY Elevator machine with complete protecting function runs smoothly and drives efficiently. Advanced microcomputer controlling system can fully monitor the running status of the moving walk.
·Stable and reliable investment: The pallet directly connecting with the chain which makes the running more smoothly and quietly, thus the service life is extended and its maintenance can be easily conducted. Special designed big wheel handrail drive runs in low noise and big power, which improves the running condition of handrail. Its life is hence prolonged. Unique tuba structure has a big load capacity, Which greatly improves the overall stability and service life.
·Colorful decoration: Various Styled handrails can meet personal demand In different environments, beautiful stainless steel floor plate has a three-dimension effect. inner and outer decking adopts
·Incomparable economical: The moving walk fully utilizes advanced manufacturing process, greatly improves product performance and service life, the most direct result is that the operation cost of the customer is reduced. The optional VF drive technology yields great energy-saving, reducing the running cost to the maximum.
|Quantity of center support beam L4||6000||10000||6000||10000|
|Motor capacity / rate current||conveyor length||conveyor length|
|Dip angle α||0-6°|
|Pedal type||aluminium allloy (indoor/half outdoor
|Pedal width A||1000||800|
|Handrail center distance B||1238||1038|
|Moving walk outside width C||1600||1400|
|Machine supporting beam length D||≥1660||≥1460|
|Installation place/drive mode||Length L1|
Use needs to supply 380V AC 50Hz three-phase five-wire power supply.Voltage should ≤10 when moving walk at the start and the voltage should be≤5in normal operation,
Maximum starting current should less than 3.5 times of rated current.
0°Moving walk construction layout drawing
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
