Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel

Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel

Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel
Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel
Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: $7000~12000
Packaging Details: wooden case
Delivery Time: 7-15working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 500 Set/ Year
Contact Now
Detailed Product Description
Name: Passenger Elevator Load: 630~1600kg
Speed: 1.0~4.0m/s Warranty: 12 Months After Shipping
Type: Elevators Product Name: Passenger Lift
Drive Type: AC Control System: VVVF Elevator Control System
High Light:

high speed lift

,

building lifts elevators



Load 630~1600kg Passenger Elevator with Flexible layout and Convenient Maintenance



Specification of passenger elevator with machine room



Load

Speed

m/s

Car size(mm) Door opening size(mm) Hoistway size(mm)

highest rise

height(m)

CW CD CH OP OPH HW HD K S
630 1 1400 1100 2500 800 2100 1850 1750 4250 1400 50
1.5 4350 1450 80
1.75 4400 1500 95
800 1 1400 1400 2500 800 2100 1850 2050 4300 1400 50
1.5 4400 1450 80
1.75 4450 1500 95
2 2000 2050 4800 1750 110
2.5 5000 1950 130
1000 1 1600 1400 2500 900 2100 2050 2050 4300 1400 50
1.5 4400 1450 80
1.75 4450 1500 95
2 2200 2100 4800 1750 110
2.5 5000 1950 130
3 2700 2300 2300 2200 5700 3600 165
4 2250 6000 4400 215
1150 1 1800 1500 2500 1100 2100 2400 220 4550 1550 50
1.5 4700 1600 80
1.75 4750 1650 95
2 4800 1750 110
2.5 5000 1950 130
3 2700 2300 2600 2200 5700 3600 165
4 2250 6000 4400 215
1350 1 2000 1500 2500 1100 2100 2500 2200 4550 1550 50
1.5 4700 1600 80
1.75 4750 1650 95
2 4800 1750 110
2.5 5000 1950 130
3 2700 2300 2600 2250 5700 3600 165
4 2300 6000 4400 215
1600 1 2000 1700 2500 1100 2100 2500 2400 4550 1550 50
1.5 4700 1600 80
1.75 4750 1650 95
2 4800 1750 110
2.5 5000 1950 130
3 2700 2300 2600 2450 5700 3600 165
4 2500 6000 4400 215





Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel 0



Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel 1



Elevator 630kg Load Electric Passenger Lift With High Speed Stainless Steel 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
