1000kg Car Space Saving Machine Roomless Cargo Freight Elevator

1000kg Car Space Saving Machine Roomless Cargo Freight Elevator

  • 1000kg Car Space Saving Machine Roomless Cargo Freight Elevator
  • 1000kg Car Space Saving Machine Roomless Cargo Freight Elevator
1000kg Car Space Saving Machine Roomless Cargo Freight Elevator
Product Details:
Place of Origin: CHINA
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Machine Roomless Freight Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15-30 days
Payment Terms: Western Union, L/C, T/T
Supply Ability: 500 set / year
Contact Now
Detailed Product Description
Type: Machine Roomless Freight Elevator Load: 1000~5000kg
Speed: 0.5~2.0m/S Business Type: Manufacturer
Color: Black Red Blue Gray Warranty: 12 Months After Shipping
Traction Machine: Permanent Magnet Synchronous Gearless Control System: VVVF Elevator Control System
Application: Medical Passenger Elevator Flooring: PVC/marble
High Light:

high speed lift

,

airport walking escalator

FUJI Stainless Steel Freight Car Cargo Passenger Elevator with Roomless Machine



FUJI Elevator series MRL freight elevator, using the advanced permanent magnet synchronous gearless traction technology, reasonable design, without room; the traction machine has the advantage of light weight, small volume saving the architectural space, greatly improve the performance and quality of machine roomless elevator, reduce energy consumption, the failure rate.
FUJI Elevator series MRL freight elevator with less shaft height, reduce the design height of the factories and other buildings, can meet the actual needs of the enterprise. To be the best choice for the transportation of goods, such as factories, warehouses, department stores, property centers, libraries and so on.


●Space saving
●Energy saving advantage
●Quiet operation



Machine Roomless (MRL) Freight Elevator Specifications

Load

(kg)

Speed

(m/s)

Exterior size of car(mm)

WxDxH

Net door opening(mm)

WxH

Door Open

Type

Shaft size(mm)
WxD OH PIT
1000 0.5 1500x1800x2200 1200x2100 Two panel side opening 2250x2200 4500 1500
1.0 4500 1500
1.5 4600 1600
2.0 4800 1800
2000 0.5 2000x2300x2200 1500x2100 Two panel side opening 3150x2660 4800 1500
1.0 5000 1500
1.5 5200 1600
2.0 5200 1800
3000 0.5 2470x2560x2200 1800x2100 Four panel center opening 3700x3000 5000 1600
5000 0.5 2800x3400x2500 2400x2400 Four panel center opening 4250x3800 6100 1600



1000kg Car Space Saving Machine Roomless Cargo Freight Elevator 0

1000kg Car Space Saving Machine Roomless Cargo Freight Elevator 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
