1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304

1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304

  • 1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304
  • 1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304
1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Small machine room gearless elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 500 Set/ Year
Contact Now
Detailed Product Description
Name: Small Machine Room Gearless Elevator Load: 1000-5000kg
Speed: 0.25-1.0m/s Warranty: 12 Months After Shipping
Material: Stainless Steel 304 Elevator Type: Goods Elevators
Product Name: Passenger Elevator Keywords: Passenger Elevator Lift
High Light:

high speed lift

,

building lifts elevators

Load 1000-5000kg Small Machine Room Gearless Elevator For Sale



Advantages
Energy energy saving, up to 39%;
Easy maintenance, no gear oil required;
Reduce the space of the machine room and save the construction cost for the owner;
Low noise and good running comfort;
Compact structure;
Meet the new national standard without additional UCM movement mechanism.



Load

(kg)

Speed

(m/s)

Door

opening

Car net size

(CWxCD)mm

(OPxOPH)mm

Shaft

(HWxHD)mm

Pit

(mm)

K

(mm)

L

(mm)

MH

(mm)

1000 0.5 one side 1432*1585 1100*2100 2350*2100 1350 4300 2500 2300
1 one side 1432*1585 1100*2100 2350*2100 1350 4300 2500
2000 0.5 one side 1732*2285 1500*2100 2700*2800 1350 4500 2000 2300
two side 1732*2138 1500*2100 2700*2800 1350 4500 2000
1 one side 1732*2285 1500*2100 2700*2800 1350 4500 2000
two side 1732*2138 1500*2100 2700*2800 1350 4500 2000
3000 0.5 one side 2000*2654 2000*2100 3450*3100 1500 4650 2000 2500
two side 2000*2608 2000*2100 3450*3100 1500 4650 2000
1 one side 2000*2654 2000*2100 3450*3100 1500 4650 2000
two side 2000*2608 2000*2100 3450*3100 1500 4650 2000
4000 0.25 one side 2000*3545 2000*2400 3450*3900 1500 4800 1500 2500
two side 2000*3408 2000*2400 3450*3900 1500 4800 1500
0.5 one side 2000*3545 2000*2400 3450*3900 1500 4800 1500
two side 2000*3408 2000*2400 3450*3900 1500 4800 1500
5000 0.25 one side 2400*3454 2400*2400 3950*3900 1500 4800 1500 2500
two side 2400*3408 2400*2400 3950*3988 1500 4800 1500
0.5 one side 2400*3454 2400*2400 3950*3900 1500 4800 1500
two side 2400*3408 2400*2400 3950*3988 1500 4800 1500



Small machine room gearless elevator construction sketch



1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304 0



1000kg Small Gearless Machine Room Less Elevator With Stainless Steel 304 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
