Product Details:
|
| Name: | Elevator Controller Cabinet | Current: | 5A |
|---|---|---|---|
| Frequency: | 50HZ Or 60HZ | Ambient Temperature: | -30℃ - ~ 60℃ |
| Transportation: | Sea Delivery | Category: | Elevator Parts |
| Business Type: | Manufacturer | Keywords: | Elevator Controller Cabinet |
| Model: | Elevator Controller Cabinet | ||
| High Light: | 5A Elevator Control Cabinet,60HZ Elevator Control Cabinet,AC380V Elevator Control Cabinet |
||
50HZ Or 60HZ 5A Power Supply Cabinet / Elevator Control Cabinet
Elevator Parts AC380V Three Phase 50HZ 60HZ 5A Elevator Control Cabinet
Introduction
This device is designed to improve the safety performance of the elevator. The device makes use of the original control and frequency conversion system of the elevator and the driving system not independent of the original elevator control system, so it has the characteristics of simple installation and wiring, convenient debugging, and high cost performance. In the process of using the elevator, once the power supply system is cut off, it will cause physical and psychological injury to the passengers trapped in the elevator. When the above situation occurs, the device will automatically put into operation within the set time, so that the elevator car will slowly run to the nearest station level, open the door and release the passengers in the light load direction.
Main technical parameters
1. Input parameters:
| Input voltage: |
Three _phase AC380V+ 10% (at AC380V) Three-phase AC220V+10% (at AC220V) |
| Frequency: | 50HZ or 60HZ |
| Battery pack: | 2x 12V/5AH(7AH/12AH) or 3x 12V/5AH (7AH ) |
2. Output parameters:
| Inverter output voltage: | Two-phase AC380V+10% (at AC380V) Two-phase AC220V+10% (at AC220V) |
| Frequency: | 50HZ or 60HZ |
|
Maximum output current: |
5A |
3. Applicable environment:
| Ambient temperature: | -30℃ - ~ 60℃ |
| Humidity: | 30%~ 75% (Non-condensing) |
Installation size
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
