Product Details:
|
Name: | Elevator Overspeed Governor | Rated Speed: | 0.25~2.5m/S |
---|---|---|---|
Rope Wheel Diameter: | Ф240mm | Speed Limit Wire Rope: | 8mm |
Used: | Elevator Parts | Voltage: | DC110 Or AC220 |
Certification: | ISO9001 | Warranty Time: | 12 Months |
Model: | Elevator Overspeed Governor | Type: | Elevator Overspeed Governor |
Highlight: | 40mm Sheave Elevator Overspeed Governor,2.5m/S Elevator Overspeed Governor,AC220V Elevator Overspeed Governor |
240 mm Sheave Diameter Elevator Safety Parts Overspeed Governor
This overspeed governor is one way
With mechanical remote reset and trigger function
Using with one way safety gear
Rated speed(m/s) | 0.25~2.5 |
Lifting height(m) | ≤110 |
Over speed switch voltage grade(V) | DC110 or AC220 |
Switch magnet voltage grade(V) | DC24 or AC220 |
Action magnet voltage grade(N) | DC24 or AC220 |
Sheave pitch(mm) | Wire rope diameter(mm) | Rope pulling force(N) | Voltage grade of solenoid(V) |
240 | 8 | 1000~2000 | DC24 |
6 | |||
8 | AC220 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
