Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts

Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts
Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts

Large Image :  Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-WFBS
Payment & Shipping Terms:
Minimum Order Quantity: 10Pcs
Packaging Details: container
Delivery Time: 7~15 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 100000 meters/ Month

Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts

Description
Name: Elevator Compensation Chain Model Number: SN-WFBS
Model Name: Elevator Compensate Chain Guide Device Other Name: Durable Elevator Compensate Chain Guide Device
Used: Elevator Parts Warranty Time: One Year
Material: Steel Model: Elevator Compensation Chain
Product: Elevator Compensation Chain
High Light:

Plastic Wrapped Elevator Compensation Chain

,

Durable Elevator Compensation Chain

,

OD 6mm Elevator Compensation Chain

Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts



Description of SN-WFBS Plastic-Wrapped balance compensating chain

High qualitychain wrapped with synthetic rubber material

Good and stable performance

Flexibility, small bending diameters, insulation, durability, aging-resistance, can word under a wide range of temperature

Low noise, recommended for elevator speed under 1.75m/s

Specification of elevator compensate chain guide device

Model number OD (mm) Weight(kg/m) Min bending Diameter(mm) Breaking load(≥KN) Max.Hanglength(m)
SN-WFBS-6 6±0.2 0.92±0.2 ≥130 15.63 154
SN-WFBS-7 7±0.2 1.23±0.2 ≥250 18.18 160
SN-WFBS-8 8±0.2 1.49±0.2 ≥260 23.68 162
SN-WFBS-9 9±0.2 1.88±0.2 ≥280 29.97 162
SN-WFBS-9.5 9.5±0.2 2.24±0.2 ≥280 33.40 162
SN-WFBS-10 10±0.5 2.35±0.2 ≥290 37.00 168
SN-WFBS-11 11±0.5 2.98±0.2 ≥290 44.70 155
SN-WFBS-12 12±0.5 3.24±0.2 ≥300 52.28 168
SN-WFBS-13 13±0.5 3.72±0.2 ≥320 62.60 172
SN-WFBS-14 14±0.5 4.46±0.2 ≥320 70.00 160
SN-WFBS-15 15±0.5 5.22±0.2 ≥320 83.25 162
SN-WFBS-16 16±0.5 5.96±0.2 ≥340 94.70 162





Plastic Wrapped Steel Elevator Compensation Chain For Elevator Parts 0



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
