Product Details:
|
| Name: | Elevator Overload Weight Measuring Sensor | Power: | ≤4W |
|---|---|---|---|
| Voltage: | AC/DC16~48V | Model: | Car Parts |
| Transportation: | DHL TNT FEDEX | Warranty Time: | One Year |
| Applicable: | Elevator Equipment | Category: | Elevator Parts |
| Type: | Elevator Overload Weight Measuring Sensor | Product: | Elevator Overload Weight Measuring Sensor |
| High Light: | 4W Elevator Weight Measuring Sensors,48V Elevator Weight Measuring Sensors,Elevator Overload Weight Measuring Sensors |
||
Weight Measuring Sensors And Lift Load Cell Control Elevator Overload Measurement System
48V 4W Elevator Overload Weight Measuring Sensor For Elevator Parts
Protection with broken and loose rope alarm function output
Rope tension unbalance alarm output and tension adjustment indication
2 load cell input channels(only the load cell which adapter can sense single steel rope or strip shall response with the features of above two )
Voltage or current analog output is optional
Cabin weighing state display indicator is optional
HOLD terminal can input wide voltage
12V-230V AC/DC
Technical Parameter
| Operating voltage | AC/DC 16~48V | Voltage analog | -10v~+10v,0V~+10V |
| Nominal power | ≤4W | Current analog | optional(4~20mA) |
| Load cell channel | 2* | Sensor operationg voltage | DC5V |
| Relay number | 6 | Signal hold voltage | AC/DC12~230V |
| Contact load | 1A 125VAC/2A 30VDC,5A 250VAC/5A 30VDC | Measuring precision | 0.1% |
| Display type | 4 digits 0.36inch LED | Operationg temperature | -45℃~+85℃ |
| Display mode | weight/percentage | Size | 90x84x58mm³ |
| Key number | 6 | Weight | 260g |
