Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
Customer Reviews
Service is people-oriented and honesty is the most attractive. It's a pleasure to cooperate with you

—— Millay

I'm Online Chat Now

Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator

Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator
Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator

Large Image :  Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: ISO9001
Model Number: SN-CP-ST/G
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $600~1500
Packaging Details: Wooden box
Delivery Time: 7 working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 5000 Pcs/ Month

Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator

Description
Name: Elevator Controller Cabinet Power Input: 50/60Hz
Power: 22kw Control System: AS380 Integrated Controller
Temperature: -10℃~45℃ Color: Gray
Warranty Time: 12 Months Applicable: For Mr And Mrl
Model: Elevator Control Cabinet Product: Elevator Control Cabinet
High Light:

22kw Elevator Control Cabinet

,

Gray Integrated Elevator Control Cabinet

,

Floor Type Elevator Control Cabinet

Lift System Machine Room Nice 3000 Power Controller Control Cabinet

Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator



Integration Serial Control Cabinet

Executive standard:GB7588/EN-81

Applicable environment temperature:-10℃~+45℃

External interface forms:AM,plug-in

Power input:three-phase 380-460-V 50/60 Hz



Model 6400 2300 2000 0100
Machine room configuration with machine room/small machine room with machine room without machine room with machine room
Installation mode wall-mounted(type A)floor type(type B) floor type installed inside the wall floor type
Adaptive band-type brake specification

DC110V<4A

DC200V/AC220V<2A

DC110V<6A

DC200V/AC220V<3A

DC110V<4A

DC200V/AC220V<2A

DC110V<6A

DC200V/AC220V<3A

Adaptive door machine type AC220V frequency conversion door machine,<1A
Power of drive components ≤AS380 22kw ≤AS380 22kw ≤AS380 22kw ≤AS380 37kw
Dimension(highXwidthXthickness)mm

900x580x300(A type)

1000x580x300(B type)

1350x650x330 1780x400x220 1650x650x382
Resistance box configuration Built-out ≤18.5kw built-in Built-out ≤22kw built-in
Standard color of cabinet body Computer gray
Contactor relay Schneider LC1-D series
Terminal 2.5m㎡ and 16m㎡ crimping terminals
Button Schneider ZB5 series
Switching power supply 100w switching power supply
Transformer JBK3Z SERIES
Switch Schneider OSMC series



Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator 0



Gray Integrated 22kw Elevator Control Cabinet Floor Type For Passenger Elevator 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
