Home ProductsElevator LCD Display

RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module

RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module

RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module
RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module
RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Monitoring Module
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Packaging Details: Standard Export Package
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500pcs/month
Contact Now
Detailed Product Description
Name: Monitoring Module System: INVT
Used: Elevator Parts Hole Size(mm): 4
Voltage: DC20V Original: Yes
Application: Elevator Warranty Time: 12 Months
High Light:

SMS Elevator Fire Alarm

,

SMS Alarm Elevator Monitoring Module

,

RS485 Communication Elevator Monitoring Module

DM-03 GSM Monitoring Module



About the Product

DM-03 is a transmission module specially designed for elevator fault alarm.
Using GSM, RS485 communication technology, informing maintenance staff directly by SMS when the elevator break down, it realizes the point-to-point connection between the elevator and maintenance personnel , reduces the delay as the network connection, and it is very suitable for areas have no network service or poor network service.



Product Features

Realize elevator SMS alarm, elevator monitoring
Elevator state monitoring: parking, maintenance, overload, fire, door open/close, etc
System service: inquiry and print of elevator information, fault, maintenance records.
Maximum 5 phone number can be set for SMS alarm



Appearance dimension(mm) Installation dimension(mm) Hole size(mm)
146x86x39 136.3 4.5



DM04A loT & Cloud Monitoring Module

About the Product

DM04A is a new generation of elevator monitoring system, which uses the latest technology of communication, IoT (Internet of Things) and cloud. Visiting the i-ESM page on browser, we can remotely control the elevator like remote elevator stopping, matching, failure enabling and other operations, and analyze, save the running data and maintenance records to enhance the management of elevator and maintenance



Product Features

Real-time monitor system on the basis of Internet
Dynamic real-time monitoring operation and early warning
Real-time failure records and warning through collection of signal, analysis failure and records of operation
Supervision and management of maintenance technician, real-time records of maintenance personnels' operation
CAN port compatible



Appearance dimension(mm) Installation dimension(mm) Hole size(mm)
124.5x76 115x38 3.5



RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module 0



RS485 Communication SMS Elevator Fire Alarm Elevator Monitoring Module 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
