Passenger Lift Elevator Electrical Parts Emergency Power Supply Device

Passenger Lift Elevator Electrical Parts Emergency Power Supply Device
Passenger Lift Elevator Electrical Parts Emergency Power Supply Device
Passenger Lift Elevator Electrical Parts Emergency Power Supply Device Passenger Lift Elevator Electrical Parts Emergency Power Supply Device

Large Image :  Passenger Lift Elevator Electrical Parts Emergency Power Supply Device

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-HCYD-XX-YTS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Packaging Details: in Carton Box
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500pcs/month

Passenger Lift Elevator Electrical Parts Emergency Power Supply Device

Description
Name: Emergency Power Supply Device Input Mode: Three-phase Five-wire System
Power Factor: 0.8 Fequency: 50Hz/60Hz
Rated Voltage: AC380V Charging Current: ≤1.5A
Transportation: Air Sea Express Warranty Time: 12 Months
Model: Emergency Power Supply Device Type: Emergency Power Supply Device
High Light:

Passenger Lift Elevator Electrical Parts

,

Emergency Power Supply Elevator Electrical Parts

,

AC380V Elevator Electrical Parts

Lift Electrical Parts / Emergency Power Device For Passenger Lift



Product Description

HCYD-XX-YTS is a special emergency rescue device for elevator power filure When the elevator is uning, the equipment is in standby state. In case of power failure or other faults, the equipment will automatically start the rescue work, output electric energy, use the elevator control system to slowly run the elevator car to the nearest level position, open the car door and hall door, so that the trapped passengers can leave the elevator quickly and safely.



Working Environment

Ambient temperature: -5°C to 50°C;
Relative humidity: <90%. No condensation;
No contain explosive, corrosive and other harmful gases or dust in the air;
No severe vibration and no strong electromagnetic interference;



Features
Using power frequency inverter system, it has strong load and impact resistance, and is not easy to damage, safe and reliable;
The integrated design makes maintenance and repair simple and convenient;
By using advanced itelligent IC control, it is not easy to be damaged and can be maintained easily, and the action sequence is more accurate. The working time can be adjusted according to customer requests;
It can realize multi-line output with different voltage levels, reducing product types;
There are multiple protections inside the device which monitors various internal components and line faults at the
same time, and outputs fault signals and displays when faults occur;
The power supply voltage can be customized according to customer requirements;
The equipment is beautiful and easy to install. It is equipped with mounting brackets and can be installed in non-bot-tom places such as walls;
There are few equipment connection lines, which makes wiring and debugging easily.
Meet the requirements of EMC safety regulations;



Passenger Lift Elevator Electrical Parts Emergency Power Supply Device 0



Passenger Lift Elevator Electrical Parts Emergency Power Supply Device 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
