2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load

2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load
2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load 2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load 2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load

Large Image :  2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: elevator safety gear
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $90~150
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Pcs/ Month

2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load

Description
Name: Progressive Safety Gear Rated Speed: 0.25~2.5 M/S
P+Q: 1200~3500 Kg Width Of Guide Rails: 10,15.88,16mm
Model: Elevator Safety Gear Used: Elevator Parts
Certifcation: GB/CE Warranty Time: One Year
Type: Progressive Safety Gear Product: Progressive Safety Gear
High Light:

2.5M/S Elevator Safety Parts

,

3500Kg Load Progressive Safety Gear

,

GB Elevator Progressive Safety Gear

Elevator Safety System Progressive Safety Gear Elevator Spare Parts

*Innovative improved design,having the commom characteristics and advantage of all  safty gears
*More competitive price
*Wedges release more safely and freely

Rated speed(m/s) Acting speedof governor(m/s) Permitted P+Q(kg) Rail width(mm) External dimension
(LxWxH)(mm)
Certifcation
0.25~2.5 0.29~3.23 1200~3500 10,15.88, 16 162x65x231 GB/CE



2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load 0



2.5M/S Elevator Safety Parts Progressive Safety Gear 3500Kg Load 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
