|Name:||Elevator Control Cabinet||Power Range:||5.5 - 22kW|
|Power Supply:||3 Phase , AC380~415V , 50/60Hz||Transportation:||Sea Transportation|
|Usage:||Mr & Mrl||Original:||CHINA|
|Model:||Elevator Control Cabinet||Product:||Elevator Control Cabinet|
EN81 Passenger Elevator Control System,
Passenger Elevator Control System 2.5m/S,
3 Phase Elevator Control System 2.5m/S
Step System Elevator Control Cabinet For Passenger Elevator Lift
Elevator Integrated Control Cabinet KC64M
Design base on EN81-20 and comply with CE.
UCMP , Self-monitoring on braking force periodically.
Door lock bypass device for bypassing hall or car door lock.
Monitoring of door lock circuit, to prevent the car door or hall door unexpectedly shorted
Protection for second brake added to ensure safer and reliable operation.
Pit inspection controlled by communication for easier inspection and maintenance.
MR Technical Indicators
|Power supply:||3 phase , AC380~415V , 50/60Hz|
|Rated power :||5.5 - 22kW|
|Rated speed :||≤2.5m/s|
Motor type :
|Motor Brake :||DC110V , ≤3A|
|Environment :||-10℃-45 ℃|
|Cabinet material :||Galvanized sheet|
Control Method :
|Single / Duplex / Group Control|
|Brake resistor cabinet dimension(mm) :||420×255×117~420×255×255|
|Installation :||Ground mounted|
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
