Product Details:
|
| Model Number: | Elevator Light Curtain | Category: | Safety Light Curtain Sensor |
|---|---|---|---|
| Name: | Light Curtain Elevator | Transportation: | Air Transportation |
| Business Type: | Manufacturer | Light Curtain: | Elevator Parts |
| Protection Height: | 144 To 1,008 Mm | Type: | Ø14/Ø20/Ø30mm |
| Product: | Safety Light Curtain Sensor | Model: | Safety Light Curtain Sensor |
| High Light: | Elevator Lift Safety Light Curtain Sensor,SFL Series safety light barrier sensor,Human Body Protection Elevator Light Curtain |
||
International Safety Standard Elevator Lift Light Curtain Sensor
Safety Light Curtains (Standard Type)
IDEA 2020 Good Design 2019 K Design 2019 Gold Pinup 2018
The SFL series safety light curtains are installed in potentially dangerous or hazardous areas to safeguard personnel from injury. The light curtains feature proven technology from Autonics area sensors and mapping sensors. The light curtains are built to meet international safety standards and regulations. Various detection models (finger/hand/hand-body detection) and safety functions are available for diverse applications.
| International safety standard and regulation compliance : Type 4 ESPE(AOPD), SIL3, SIL CL3, Category 4, PL e, CE, UL Listed, S-Mark, KCs(Select models) |
| 3 detection type models available (finger, hand, hand-body detection) |
| Various models by protection height : Ø14 mm (finger detection type) 144 to 1,008 mm : Ø20 mm (hand detection type) 183 to 1,023 mm : Ø30 mm (hand-body detection type) 1,025 to 1,850 mm |
| Various safety-related functions & self-diagnosis functions - Safety-related : interlock, lockout, EDM, muting, override, blanking, reduced resolution, etc. - Self-diagnosis : mutual interference protection, ambient light detection, malfunction sensor detection |
| Selectable detection distance (short/long mode) & Switch control output settings (NPN/PNP output) |
| Operation status reading with 7-segment display and LED indicators |
| Easy beam adjustment with top and bottom beam indicators |
| Output display indicator on top displays light received/blocked status and muting status. Additional lamp not required. |
| 4 non-safety outputs for various applications (2 AUX, 2 lamp) |
FAQ
Q1: Is there free samples?
A: Yes,we could offer free sample if the unit price is less than 10usd, please contact me.
Q2: Customized logo on the elevator parts?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter, there is min order quantity.
Q3: Get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
Q4: Inspection procedures for elevator parts?
A: 100% self-inspection before packing.
Q5: Mix the 20ft container?
A: Yes,let us know your requirments please
Q6: Visit to your company before the order?
A: Sure,welcome to visit us. Our location is near by Shanghai Hongqiao airport.
Q7: By paypal and western union or cash or CNY?
A: Yes,please contact us for detail.
Q8: Delivery time of the parts?
A: Depend on the products your asked, please contact us for detail.
Q9: How to place order?
A: 1.let us know your requirment; 2 confirm the detail we will make proforma invoice for you; 3.send us payment and bankslip,or you could pay on alibaba we will release work order accordingly.4.We will send goods to you with the shipping metherd we confirmed.
