Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems

Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems
Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems
Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems

Large Image :  Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SFLA Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $20~50
Packaging Details: 1Pcs/Roller, 10Pcs/Carton
Delivery Time: 7~15 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 10000 Pcs/ Month

Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems

Description
Category: Elevator Parts Model Number: Elevator Light Curtain
Name: Light Curtain Elevator Transportation: Air Transportation
Business Type: Manufacturer Light Curtain: Elevator Parts
Protection Height: 144 To 18688 Mm Product Name: Light Curtain
High Light:

Elevator Lift Safety Light Curtains

,

Elevator Control Safety Light Curtains

,

elevator parts Safety Light Curtains

Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems



Safety Light Curtains (High Performance Type)
IDEA 2020 Good Design 2019 K Design 2019 Gold Pinup 2018

The SFLA series safety light curtains are installed in potentially dangerous or hazardous areas to safeguard personnel from injury. The light curtains feature proven technology from Autonics area sensors and mapping sensors. The light curtains are built to meet international safety standards and regulations. Various detection models (finger/hand/hand-body detection) and safety functions are available for diverse applications. The dedicated software atLightCurtain allows real-time status monitoring user settings such as automatic muting/blanking area functions.

Main features

International safety standard and regulation compliance
: Type 4 ESPE(AOPD), SIL3, SIL CL3, Category 4, PL e, CE, UL Listed, S-Mark, KCs(Select models)
3 detection type models available (finger, hand, hand-body detection)
Various models by protection height (144 to 1,868 mm)
Various safety-related functions & self-diagnosis functions
- Safety-related : interlock, lockout, EDM, muting, override, blanking, reduced resolution, etc.
- Self-diagnosis : mutual interference protection, ambient light detection, malfunction sensor detection
Selectable detection distance (short/long mode) & Switch control output settings (NPN/PNP output)
Operation status reading with 7-segment display and LED indicators
Easy beam adjustment with top and bottom beam indicators
Output display indicator on top displays light received/blocked status and muting status. Additional lamp not required.
4 non-safety outputs for various applications (2 AUX, 2 lamp)
Detail function settings with dedicated software atLightCurtain (SFLA models)





Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems 0



Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems 1



Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems 2

Passenger Elevator Lift Safety Light Curtains For Elevator Control Systems 3
