Unidirectional Progressive Safety Gear For Passenger Elevator Parts

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
Customer Reviews
Service is people-oriented and honesty is the most attractive. It's a pleasure to cooperate with you

—— Millay

I'm Online Chat Now

Unidirectional Progressive Safety Gear For Passenger Elevator Parts

Unidirectional Progressive Safety Gear For Passenger Elevator Parts
Unidirectional Progressive Safety Gear For Passenger Elevator Parts Unidirectional Progressive Safety Gear For Passenger Elevator Parts

Large Image :  Unidirectional Progressive Safety Gear For Passenger Elevator Parts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: WSGB13
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $80~200
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Pcs/ Month

Unidirectional Progressive Safety Gear For Passenger Elevator Parts

Description
Name: Elevator Parts Safety Gear Rated Speed: 12.5 M/S
P+Q: 2800~10000 Kg Width Of Guide Rails: 9,16mm
Model: Elevator Safety Gear Used: Elevator Parts
Certifcation: GB/CE Warranty Time: One Year
Highlight:

Unidirectional Progressive Safety Gear

,

Progressive Elevator Safety Parts

,

Passenger Elevator Safety Gear

Uni-Directional Progressive Safety Gear For Passenger Elevator Parts

Description

Uni-directional progressive safety gear for super high speed
Single-direction progressive safety gear applicable for mid and high rise applications. Superb solution for car but also counterweight frame installation (modernization packages available). Brake pads from the automotive industry prevent wear on guide rails. Available for many global major elevator norms and directives.



USP's

  • Safety gear acting in downward direction
  • Constant brake force generated by preloaded disk springs
  • Steady deceleration along whole braking distance
  • Designed to avoid wearing marks to guide rail
  • Several options for different applications are available
  • Modernization packages available
Type Load on
Safety
[kg]
max. Rated
Speed V [m/s]
Guide
rail [mm]
WSGB13 2800 - 10.000 12.5 16 - 9 machineddry
WSGB13D 10.000 - 19.231 16 - 32




Unidirectional Progressive Safety Gear For Passenger Elevator Parts 0



Unidirectional Progressive Safety Gear For Passenger Elevator Parts 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
