2.0m/S Elevator Safety Gear For Guide Rail Application

2.0m/S Elevator Safety Gear For Guide Rail Application
2.0m/S Elevator Safety Gear For Guide Rail Application

Large Image :  2.0m/S Elevator Safety Gear For Guide Rail Application

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: CSGB-01C - Unidirectional
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $80~200
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Pcs/ Month

2.0m/S Elevator Safety Gear For Guide Rail Application

Description
Name: Elevator Safety Gear Rated Speed: 2.0 M/S
P+Q: 575~2700 Kg Width Of Guide Rails: 9,16mm
Model: Elevator Safety Gear Used: Elevator Parts
Certifcation: GB/CE Warranty Time: One Year
Product: Elevator Safety Gear
High Light:

2.0m/S Elevator Safety Gear

,

Guide Elevator Safety Gear

,

Elevator Instantaneous Safety Gear

2.0m/S Elevator Safety Gear Wide Application Range Of Guide Rail



Description

  • Down-direction only
  • Integration in vertical/horizontal frame beams available on request
  • High safety ratio with brake system in pair
  • Complete traceability of the production of main components from raw material to final
    product with coding system stamped to each unit to enhance safety standard
  • Less harmful on the guide rail
  • Low wear rate of the tripping wedge
  • Easy operation, maintenance-free
  • Wide application range of guide rail (Machined guide type Oiled/ Dry)
  • Very high safety factor which exceed GB7588 and EN81-1/2/20/50 rules
  • Less release force
  • 100% tested and checked at factory
Machined guide type mass to be gripped
(P+Q) Fmax
max. nominal speed
V
max. governor tripping speed
Vmax
Oiled 575-2700 (GB 7588)
1000-2700 (CE)
2.00 2.62
Dry 575-2700 (GB 7588)
1000-2700 (CE)
2.00 2.62



2.0m/S Elevator Safety Gear For Guide Rail Application 0



2.0m/S Elevator Safety Gear For Guide Rail Application 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
