Product Details:
|
Name: | Car Door | Average Power Consumption: | 60W |
---|---|---|---|
Model: | WITTUR | Protection Class: | IP20 |
CO: | 700~1000mm | Used: | Elevator Parts |
Transportation: | By Air/sea | Business Type: | Manufacturer |
Type: | Car Door | Product: | Car Door |
High Light: | Elevator Parts IP54 Door Operator,IP54 Residential Elevator Door Operator,Elevator Door Operator 60W |
Accessory
Materials
|
Categories
|
Categories
|
Notes
|
Accessories
Pack
|
Panel top
fixing pack
|
Hanger bolts
Panel fixing plates
Fasteners
|
Standard |
Panel shoe
fixing pack
|
Door guide shoe
Shims
Fasteners
|
||
DOP fixing
pack
|
Square Nuts M10
Fasteners
|
||
Triangular key | Triangular key | ||
Cable fixing
pack
|
Fasteners | ||
Light Curtain
(Dynamic)
|
Light curtain
pack
|
Light curtain
WSE-EVO
|
Optional |
Accessories | |||
Brackets Pack | DOP brackets | DOP brackets |
Standard
Installing
DOP on car
roof |
Motor Data
Motor Type | KUNPENG |
Motor Characteristics | Permanent Magnet Synchronous Motor |
Drive | SVPWM-Converter |
Average Power
Consumption
|
60W
|
Max Momentary Power
Consumption
|
120W |
Maximum Movable
Masses
|
160 Kg |
Shaft Room
Temperature
|
-25...+55°C
|
Emergency Battery
Drive
|
220 VAC
max 2.5A
|
IP Class | IP54(only for motor) |
*** Data above is default settings.
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
