Two Speed Elevator Door Operator Side Opening Variable Frequency

Two Speed Elevator Door Operator Side Opening Variable Frequency

Two Speed Elevator Door Operator Side Opening Variable Frequency
Two Speed Elevator Door Operator Side Opening Variable Frequency
Two Speed Elevator Door Operator Side Opening Variable Frequency
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-DM-1407A
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month
Contact Now
Detailed Product Description
Name: Two-Speed Door Operator Certificate: ISO9001 / CCC / CE
Related Door: Side-opening Door CO: 700~1800mm
Used: Elevator Parts Transportation: By Air/sea
Business Type: Manufacturer Type: Two-Speed Door Operator
Product: Two-Speed Door Operator Voltage: AC 220V
High Light:

Elevator Door Operator Motor Two Speed

,

Side Opening VVVF Door Operator

,

Elevator Car Door Operator Variable Frequency

Two-Speed Door Operator For Elevator ,Side Opening Variable Frequency

PRODUCT DESCRIPCTION

  1. SN-DM-1407A Door Machine
  2. Corresponding to SN-DM-1207 two-speed landing door device
  3. AC variable frequency and voltage regulation control
  4. Special interface is connected with elevator system for variable frequency control
  5. Operating voltage in variable frequency mode: AC 220V
  6. Car door lock function
  7. Directly mounted on straight beam of the car
  8. The figure indicates left opening, and the right opening is manufactured symmetrically
  9. [C" is the distance between the inside of straight beam and fast-door borderline
Net Door Opening Width Machine Length(mm)
700 1260
800 1410
900 1560
1000 1710
1100 1860
1200 2010
1300 2160
1400 2310
1500 2460
1600 2610
1700 2760
1800 2910




Overall dimensions and mounting dimensions

Two Speed Elevator Door Operator Side Opening Variable Frequency 0



Two Speed Elevator Door Operator Side Opening Variable Frequency 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
