Automatic Reset Elevator Polyurethane / Oil Buffer 900Kg - 2500Kg

Automatic Reset Elevator Polyurethane / Oil Buffer 900Kg - 2500Kg

  • Automatic Reset Elevator Polyurethane / Oil Buffer 900Kg - 2500Kg
Automatic Reset Elevator Polyurethane / Oil Buffer 900Kg - 2500Kg
Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-0BA70
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $15~150
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month
Contact Now
Detailed Product Description
Name: Elevator Polyurethane Buffer Model: Elevator Polyurethane Buffer
Used: Elevator Parts Size: Na
Choose: Manually Reset Or Automatic Reset P+Q: 900-2500kg
Free State Height: 300mm Rated Speed: 1.0m/s
Plunger Stroke: 70mm Type: Elevator Polyurethane Buffer
High Light:

2500Kg Elevator Polyurethane Buffer


Elevator Polyurethane Oil Buffer


Automatic Reset Elevator Oil Buffer

Elevator Oil Buffer 900Kg - 2500Kg Elevator Polyurethane Buffer


Type Load-bearing Range Kg Plunger Stroke mm Free State Height mm About Oil Cubage L Rated Speed m/s A
B mm
0BA70 900-2500 70 300 0.48 1.0 80 210
0BD220 600-2500 225 780 1.3 1.75 100 210
0BD290 800-2500 294 920 2.0 2.0 100 210
0BD450 1200-5000 450 1410 3.75 2.5 100 210
Automatic Reset Elevator Polyurethane / Oil Buffer 900Kg - 2500Kg 0


Automatic Reset Elevator Polyurethane / Oil Buffer 900Kg - 2500Kg 1


1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
