Product Details:
|
| Name: | Door Motors | Protective Class: | IP21 |
|---|---|---|---|
| Used: | Elevator Parts | Warranty Time: | One Year |
| Business Type: | Manufacturer | Packing: | Wooden Box |
| Applicable: | Elevator Equipment | Insulation Class: | F |
| Power: | 7.5~37kw | Working System: | S2/0.5h |
| Product: | Door Motors | Type: | Door Motors |
| High Light: | Permanent Magnet DC Elevator Door Motors,Three Phase Asynchronous Elevator Door Motors,Lift Three Phase Asynchronous Motors |
||
Three Phase Asynchronous Permanent Magnet DC Door Motors For Elevator Lift
Three-phase asynchronous motors have steel casing and frequency conversion motors.
1.Motor for door machine of elevator / lift
2.Protective class : IP21
3.Insulation class : F
Main Technical Parameters
| Model | Power (kW) |
Voltage (V) |
Current (A) |
Rotate Speed (r/min) |
Frequency (Hz) |
Installation Model | Protective Class | Insulation Class | Working System | Noise (Sound Pressure Level) |
| SN-JRF132-4 | 7.5 | 340 | 18.5 | 1770 | 60 | IM3019 | IP21 | F | S2/0.5h | 60 |
| SN-JRF160-4 | 11 | 300 | 29.6 | 1460 | 50 | IM9019 | IP21 | F | S2/0.5h | 58 |
| SN-JRF200-4 | 37 | 300 | 102 | 925 | 32 | IM3019 | IP21 | F | S2/0.5h | 68 |
Main Technical Parameters
| Type | Rated Power | Rated Rotate Speed | Rated Voltage | Efficiency | Starting Torque |
| SN-ZYM100-140 | 100W | 140r/min | 110V | 70% | ≥3.2N.m |
| Noise | Insulation Class | Working System | Installation Mode | Cooling Mode |
| ≤60dB(A) | B | S1 | IMB5 | IC00 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
