16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device

16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device
16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device 16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device

Large Image :  16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-SG-L20
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $ 90-150
Packaging Details: Wooden box
Delivery Time: 7 working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 5000 Pcs/ Month

16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device

Description
Name: Progressive Safety Gear Type: Elevator Parts
Speed: ≤4.0m/s P+Q: 2800~1800kg
Tripping Speed: ≤5.6m/s Model: Car Parts
Product: Progressive Safety Gear Product Name: Progressive Safety Gear
High Light:

Elevator Progressive Gear Brake

,

Progressive Safety Gear Brake Device 19mm

,

16mm Elevator Safety Brake

16mm/19mm Elevator Safety Spare Parts Progressive Safety Gear Brake Device



Type: SN-SG-L20
Rated speed : ≤4.0m/s
Tripping speed: ≤5.6m/s
Total mass(P+Q): 2800~1800kg
Width of rails'guiding surface: 16mm/19mm
Type: SN-SG-L21
Rated speed : 4.0m/s≤V≤6.0m/s
Tripping speed: ≤8.3m/s
Total mass(P+Q): 4000~7000kg
Width of rails'guiding surface: 16mm/19mm



16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device 0



16mm / 19mm Elevator Safety Spare Parts Progressive Gear Brake Device 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
