Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S

Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S
Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S

Large Image :  Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Elevator Oil Buffer
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $30~100
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S

Description
Name: Elevator Oil Buffer Model: Elevator Oil Buffer
Used: Elevator Parts Size: Na
Product: Elevator Oil Buffer P+Q: 3000kg
Rated Speed: ≤2.5m/s Warranty Time: One Year
Category: Elevator Parts Applicable: Passenger Lift
High Light:

3000kg Elevator Oil Buffer

,

Oil BSafety Lift Car Buffer

,

2.5m/S Elevator Oil Buffer

Passenger Elevator Spare Parts Elevator Oil Buffer Elevator Safety Parts



Type rated speed max impact speed min/max load stroke/height
SN-OBH32 3.0m/s 3.45m/s 2000/8000kg 680/1701mm
SN-OBH35 3.5m/s 4.02m/s 860/2103mm
SN-OBH40 4.0m/s 4.6m/s 2400/8000kg 1112/2688&2730*1 mm
SN-OBH50 5.0m/s 5.75m/s 1600/7600kg 1740/4190&4216*1 mm
SN-OBH56 5.6m/s 6.5m/s 2000/6500kg 2170/5140mm
SN-OBH58 5.8m/s 6.67m/s 2350/9600kg 2270/5683mm



Type rated speed max impact speed min/max load stroke/height
SN-OB16 1.6m/s 1.84m/s 700/5300kg 175/625mm
SN-OB18 1.8m/s 2.08m/s 230/765mm
SN-OB20 2.0m/s 2.34m/s 290/915mm
SN-OB23 2.3m/s 2.60m/s 350/1080mm
SN-OB25 2.5m/s 2.88m/s 435/1300mm
SN-OB29 2.9m/s 3.25m/s 550/1595mm
SN-OB31 3.1m/s 3.62m/s 680/1920mm
SN-OB35 3.5m/s 4.09m/s 1300/5300kg 860/2365mm
SN-OB40 4.0m/s 4.6m/s 1300/6600kg 1112/3000mm
Type rated speed max impact speed min/max load stroke/height
SN-OBL16 1.6m/s 1.84m/s 400/2500kg 180/530mm



Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S 0

Passenger Elevator Oil Buffer Lift Safety Parts 3000kg 2.5m/S 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
