Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With

Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With
Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With

Large Image :  Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: F819 S-FC
Payment & Shipping Terms:
Minimum Order Quantity: 1 meter
Price: $0.5~5meter
Packaging Details: Wooden box
Delivery Time: 7 working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 100000 meters/ Month

Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With

Description
Name: Gustav Elevator Rope Speed: <4m/s
Used: Elevator Parts Size: Na
Applicable: Passenger Lift Warranty: 1 Year
Nominal Rope Diameter: 8~19 Model: Gustav Elevator Rope
Product: Gustav Elevator Rope
High Light:

Elevator Wire Rope 8x19 Seale

,

Fiber Core Elevator Safety Wire Rope

,

8mm Passenger Elevator Rope

Elevator Safety Parts Gustav Elevator Rope With 8 X 19 Seale With Fiber Core



Elevator rope with fiber core

This rope has a proven history, is used in many standard elevators and is proven in Europe and many other countries worldwide. You can still trust in this rope design today.



Properties

  • long life service
  • light and flexible
  • fiber core from our own production

Technical data

Construction: 8 x 19 Seale with fiber core, regular lay

technical terms of delivery to DIN EN 12385, ISO 4344

load bearing wires in the outer strands: 152



rope-Ø (permissible tolerance)
no load: with load (10% of Fmin):
max. 6% < 10 mm min. -0% <= 10 mm
max. 5% > 10 mm min. -0% > 10 mm



* No stock material

rope diameter (mm) calculated mass (kg/m) min. breaking load (kN) part-no.
8 0,215 30,5 621208014
9 0,27 38,4 621209010
10 0,34 48,2 621210013
11 0,411 58,4 621211013
12 0,488 69,2 621212013
13 0,579 80,7 621213013
14* 0,667 93 621214013
15* 0,774 108 621215013
16 0,871 121 621216013
18* 1,087 154 621218013
19 1,218 171 621219013





Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With 0

Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With 1



Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With 2



Fiber Core Elevator Safety Components Wire Rope 8 X 19 Seale With 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
