Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves

Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves
Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves

Large Image :  Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: F819 S-FC-DT
Payment & Shipping Terms:
Minimum Order Quantity: 1 meter
Price: $0.5~5meter
Packaging Details: Wooden box
Delivery Time: 7 working days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 100000 meters/ Month

Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves

Description
Name: Gustav Elevator Rope Speed: <4m/s
Used: Elevator Parts Size: Na
Applicable: Passenger Lift Warranty: 1 Year
Nominal Rope Diameter: 8~19 Model: Gustav Elevator Rope
Product: Gustav Elevator Rope
High Light:

Fiber Core Elevator Rope

,

Traction Sheaves Elevator Wire Rope

,

Elevator Components Wire Rope 8mm

Gustav Elevator Rope With Fiber Core Particularly Suitable For Softer Traction Sheaves



Elevator rope with fiber core

This rope is used in many standard elevators and has a proven history both in Europe and many other countries worldwide. Because of the dual tensile grade of the wires in the strands, this type may be used on softer traction sheaves. Thus, the hardness ratio rope/sheave is shifted towards the sheave.

Particularly for North America, you will find an even lower tensile grade of just 1180 N/mm2 outer strand hardness. See separate 4th Edition catalogue of Elevator Ropes for North America which you can also download.


Properties

  • particularly suitable for softer traction sheaves
  • excellent service life
  • light and flexible

Technical data

Construction: 8 x 19 Seale with fiber core, regular lay

technical terms of delivery to DIN EN 12385, ISO 4344; BS 302-4

load bearing wires in the outer strands: 152

rope-Ø (permissible tolerance)
no load: with load (10% of Fmin):
max. 6% < 10 mm min. -0% <= 10 mm
max. 5% > 10 mm min. -0% > 10 mm



* No stock material

rope diameter (mm) calculated mass (kg/m) min. breaking load (kN) part-no.
8 0,22 30,5 621108011
9* 0,28 38,4 621109011
10 0,35 48,2 621110011
11 0,43 58,4 621111011
12 0,5 69,2 621112011
13 0,59 80,7 621113011
14* 0,68 93 621114011
15* 0,78 108 621115011
16 0,89 121 621116011
18 1,11 154 621118011
19* 1,26 171 621119012



Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves 0

Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves 1



Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves 2



Fiber Core Gustav Elevator Wire Rope For Softer Traction Sheaves 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
