Product Details:
|
| Name: | Integrated Controller | Power Range: | 5.5-15kw |
|---|---|---|---|
| Size: | 970*430*220 Mm | Safety Standard: | EN81 |
| Power Supply: | 3 Phase , AC380~415V , 50/60Hz | Transportation: | Sea Transportation |
| Usage: | Mr & Mrl | Original: | CHINA |
| Model: | Integrated Controller | Product: | Integrated Controller |
| High Light: | Integrated Elevator Control System,15kw Elevator Integrated Controller,Elevator Integrated Controller NICE3000 |
||
15kw NICE3000 New Integrated Controller With More Environmentally Friendly
Product description
NICE3000-B series elevator integrated control cabinet is an elevator control cabinet system independently designed and produced by Inovance Technology. We provide customers with a series of elevator solutions and comprehensive solutions that meet the new national standards. Various needs of customers. This series of control cabinets adopts a new structural design, the overall appearance is beautiful, the layout is reasonable, and the materials used are cleaner and more environmentally friendly; a new generation of NICE3000new integrated controller is adopted, and only one parameter needs to be modified to drive AC asynchronous motors and permanent magnets respectively. The synchronous motor is safe, reliable and energy-saving, while reducing the number of accompanying cables, and the user interface is fixed, which is convenient for users to use and maintain.
Product features and advantages
simple 30% reduction in the number of cores of accompanying cables Cables between the car roof and the car are reduced by 60%
| Type | Size(mm) | Installation Mode |
|---|---|---|
| 5.5-15kw | 970*430*220 | wall-mounted/floor-mounted |
| 18.5-22kw | 1220*470*250 | floor-mounted |
| 30-37kw | 1320*510*275 | floor-mounted |
| Type | Size(mm) (No resistance box) |
|---|---|
| 5.5-22kw | 350*240*1350mm |
| 30-37kw | 400*250*1500mm |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
