Seamless Structural Electromagnetic Geared Traction Machine 800 KG

Seamless Structural Electromagnetic Geared Traction Machine 800 KG
Seamless Structural Electromagnetic Geared Traction Machine 800 KG Seamless Structural Electromagnetic Geared Traction Machine 800 KG Seamless Structural Electromagnetic Geared Traction Machine 800 KG Seamless Structural Electromagnetic Geared Traction Machine 800 KG

Large Image :  Seamless Structural Electromagnetic Geared Traction Machine 800 KG

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE, ISO9001
Model Number: SN-TMYJ186
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: T.T, Western Union, Paypal, L.C
Supply Ability: 5000pcs/month

Seamless Structural Electromagnetic Geared Traction Machine 800 KG

Description
Product Name: Geared Traction Machine Speed: 0.5-1.6 M/s
Weight: 500 KG Load: 800 KG
Voltage: 220/380 V Power: 5.5 KW
Model: Geared Traction Machine Type: Geared Traction Machine
High Light:

elevator traction motor

,

traction elevator components

,

800 KG elevator geared machine

Geared Traction machine for Elevator Machine Room Less by Elevator Parts Company, Load 800 KG , SN-TMYJ186

Seamless Structural Electromagnetic Geared Traction Machine 800 KG



Seamless Structural Electromagnetic Geared Traction Machine 800 KG 0



  • High efficiency, energy saving;
  • Seamless structural design with mini distortion;
  • High efficient of the electromagnetic, low temperature rise;
  • Low operation noise, smooth running;



Seamless Structural Electromagnetic Geared Traction Machine 800 KG 1

Model Number Roping Load(kg) Speed(m/s) Sheave Diam-Rope Diam x Groove No.-Groove Pitch (mm) Power(Kw) Ratio Pole RPM Current(A)
SN-YJ186 1:1 800 0.5 Ø520-Ø13x5-20 5.5 47:1 6 960 12.5
1:1 800 0.63 Ø520-Ø13x5-20 5.5 61:1 4 1440 11.8
1:1 800 0.8 Ø520-Ø13x5-20 7.5 47:1 4 1440 15.1
1:1 800 1.0 Ø520-Ø13x5-20 9 47:2 6 960 19.5
1:1 800 1.26 Ø520-Ø13x5-20 11 61:2 4 1440 22.8
1:1 800 1.6 Ø520-Ø13x5-20 13 47:2 4 1440 26
1:1 1000 0.5 Ø520-Ø16x5-20 5.5 47:1 6 960 12.5
1:1 1000 0.63 Ø520-Ø16x5-20 7.5 61:1 4 1440 15.1
1:1 1000 0.8 Ø520-Ø16x5-20 9 47:1 4 1440 18.5
1:1 1000 1.0 Ø520-Ø16x5-20 11 47:2 6 980 24
1:1 1000 1.26 Ø520-Ø16x5-20 13 61:2 4 1440 26
1:1 1000 1.6 Ø520-Ø16x5-20 15 47:2 4 1440 30



Seamless Structural Electromagnetic Geared Traction Machine 800 KG 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
