Product Details:
|
| Name: | EMERGENCY POWER SUPPLY DEVICE | Capacity: | 11KW |
|---|---|---|---|
| Power Factor: | 0.8 | DC Voltage: | 48 Vdc |
| Crest Factor: | 4:1 | Harmonic Distortion: | ＜3% On Linear Load |
| Product Name: | TPS Single Phase | Product: | TPS Single Phase |
| Type: | TPS Single Phase | ||
| High Light: | TPS Single Phase Elevator Electrical Parts,TPS Elevator Electrical Parts,11KW Elevator Electrical Parts |
||
Elevator Electrical Parts TPS Single Phase LCD Display Smart CPU Control For Easy Installatio
(Single Phase)
| Model | TPS-5.5S | TPS-7.5S | TPS-11S | |
| Capacity | 5.5 KW | 7.5 KW | 11 KW | |
| AC Input |
220Vac +/- 20% Single Phase Input (or 380Vac +/- 20% Single Phase Input) 50/60Hz ± 10% |
|||
| DC Voltage |
24 Vdc (12V/7Ah * 2pcs) |
36 Vdc (12V/7Ah * 3pcs) |
48 Vdc (12V/7Ah * 4pcs) |
|
| Charger Type | Controlled Rectifier CVCC | |||
| Charging Time | 10 Hours for 90% of Full Battery Capacity | |||
| Inverter | Technology | IGBT based PWM Sine Wave | ||
| Output Voltage | 220Vac Single Phase (or 380Vac Single Phase), 50/60Hz ± 0.1Hz | |||
| Inverter Efficiency | 85% | |||
| Overload | 105% continuous | |||
| Harmonic Distortion | <3% on Linear load | |||
| Crest Factor | 4:1 | |||
| Power Factor | 0.8 | |||
| Phase Displacement | 120° ± 1° | |||
| LCD Display | AC normal, Inverter normal, Batter low, Overload | |||
| Protection |
Output Overload & Short circuit , DC Under & Over Voltage |
|||
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
