Product Details:
|
| Name: | Elevator Light Curtain | Lowest Beam: | ≤10mm |
|---|---|---|---|
| Category: | Elevator Parts | Business Type: | Manufacturer |
| Model: | Elevator Light Curtain | Type: | Elevator Light Curtain |
| Operating Temperature Range: | -20℃~+65℃ | Distance Betweon Diodes: | 48mm |
| Angular Displacement At 50mm: | ±7° | Light Immunity: | ≥100,000LUX |
| IP Rating: | IP54 | ||
| Highlight: | Homelift Light Curtain In Elevators,Precise Detection Homelift Light Curtain |
||
SN-SFT-340 Homelift Light Curtain With 40 Pairs Of Diodes For Precise Detection In Elevators
| Model | SN-SFT-340 | |
| Number of diodes | 40 Pairs | |
| Distance between diodes | 48mm | |
| Maximum beams(distance≥400mm) | 194 Beams | |
| Minimum beams(distance<400mm) | 118 Beams | |
| Highest beam | ≥1810mm | |
| Lowest beam | ≤10mm | |
| Size | 18.5mm(thickness)×13.4mm(width)×2070mm(height) | |
| Detecting distance | 0-3500mn | |
| Vertical displacement at 0mm | ±20mm | |
| Horizontal displacement at 0mm | ±3mm | |
| Angular dlsplacement at 50mm | ±7° | |
| work reliability | 2 million door movements | |
| Light immunity | ≥100,000LUX | |
| EMC compliance | Emissions to EN12015, Immunity to EN12016 | |
| Operating temperature range | -20℃~+65℃ | |
| IP Rating | IP54 | |
| Vibration tost | The vibration frequency is 10-55HZ,the amplitude is 0.75mm, Vibration direction:X,Y,Zthree axial each 50min |
|
| Respones Time(NPN or PNP) | 65ms | 75ms |
| Respones Time(Relay) | 80ms | 90ms |
FAQ
Q1: Is there free samples?
A: Yes,we could offer free sample if the unit price is less than 10usd, please contact me.
Q2: Customized logo on the elevator parts?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter, there is min order quantity.
Q3: Get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
Q4: Inspection procedures for elevator parts?
A: 100% self-inspection before packing.
Q5: Mix the 20ft container?
A: Yes,let us know your requirments please
Q6: Visit to your company before the order?
A: Sure,welcome to visit us. Our location is near by Shanghai Hongqiao airport.
Q7: By paypal and western union or cash or CNY?
A: Yes,please contact us for detail.
Q8: Delivery time of the parts?
A: Depend on the products your asked, please contact us for detail.
Q9: How to place order?
A: 1.let us know your requirment; 2 confirm the detail we will make proforma invoice for you; 3.send us payment and bankslip,or you could pay on alibaba we will release work order accordingly.4.We will send goods to you with the shipping metherd we confirmed.
