Product Details:
|
| Name: | 2 Panel Center Opening PM Synchronous Door Operator | Opening Mode: | Center Opening |
|---|---|---|---|
| Model: | Door Operator | Type: | 2 Panel Center Opening PM Synchronous Door Operator |
| CO: | 600~1200mm | Used: | Elevator Parts |
| Transportation: | By Air/sea | Business Type: | Manufacturer |
| Product: | 2 Panel Center Opening PM Synchronous Door Operator | Door Panel: | 1.2mm/1.5mm |
| Highlight: | PM Synchronous Door Panel Operator,1.2mm Door Panel Operator,1.5mm Door Panel Operator |
||
1.2mm/1.5mm Door Panel 2 Panel Center Opening PM Synchronous Door Operator
The 2 Panel Center Opening PM Synchronous Door Operator is a sophisticated and efficient system designed for seamless operation of double-door configurations. This advanced door operator is engineered to synchronize the movement of two door panels, ensuring they open and close in perfect harmony. It is particularly suited for high-traffic areas such as commercial buildings, hospitals, and airports, where smooth and reliable door operation is essential.
The system utilizes a permanent magnet (PM) synchronous motor, which offers superior performance in terms of energy efficiency, precision, and quiet operation. The synchronous motor ensures consistent speed and torque, even under varying load conditions, making it highly reliable for frequent use. The center-opening design allows the two door panels to move symmetrically from the center, maximizing space utilization and providing a wide, unobstructed entrance.
Equipped with advanced control features, the operator supports customizable opening and closing speeds, hold-open times, and safety sensors to detect obstacles, ensuring user safety and compliance with accessibility standards. Its robust construction and low maintenance requirements make it a durable and cost-effective solution for modern architectural needs. Overall, the 2 Panel Center Opening PM Synchronous Door Operator combines cutting-edge technology with user-friendly functionality, delivering a seamless and secure door operation experience.
| PL | 600 | 700 | 800 | 900 | 1000 | 1100 | 1200 |
| L1 | 1270 | 1470 | 1670 | 1870 | 2070 | 2270 | 2470 |
| L2 | 1240 | 1440 | 1640 | 1840 | 2040 | 2240 | 2440 |
| HL | 2000~2500(mm) | ||||||
| PL | 600~1300 |
| HL | 2000~2500 |
| Motor | 2.3NM/47W |
| Ip Rating | IP2X |
| Noise Level | ≤58dB |
| Door Vane | Integrated with car door lock |
| Guide Rail Type | Solid guide rail |
| Door Panel | 1.2mm/1.5mm |
| Max.Drag | 160Kg |
| Installation Method | Car top /Lintel |
| Car Sill | Aluminum sill 54mm |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
