Elevator Sliding Guide Shoes Width Of Guide Rails 9mm/10mm/16mm

Elevator Sliding Guide Shoes Width Of Guide Rails 9mm/10mm/16mm

Product Advantage

This product is mainly used on the counterweight side, in the positive pressure direction of the guide rail. The spring and rubber are adopted for shock absorption. The shoe head can be rotated, and the position error caused by the uneven bottom beam of the car can be eliminated. The shoe lining of this product is made of ultrahigh molecular weight polyethylene, which is provided with high wear resistance.

Product Specifications

Rated Loading Capacity	≤2000kg
Name	Slide speed guide shoe
Positive Pressure of the Guide Surface (N)	≤2000
Lateral Pressure of the Guide Surface (N)	≤2000
Rated Speed	≤2.0m/s
Width of Guide Rails	9mm/10mm/16mm

FAQ

1. 1. Are the elevator wire ropes durable? The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. 2. Is it dangerous for power failure suddenly during the elevator running? If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. 3. Will us be hurt when it closed suddenly? In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. 4. How the elevator running? Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. 5. Is the escalator installation complicated? We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. 6. Do you have any cerifications? Yes, we do with ISO9001 / CCC / CE Certificates for u.
