EN 81-20 Certified Elevator Safety Overspeed Governor Elevator Speed Governor System
The Elevator Speed Governor is an essential component of elevator safety. It plays a crucial role in ensuring the well-being of passengers and protecting their lives and property.
During the operation of an elevator, there may be various reasons that can lead to overspeed or loss of control, even posing a risk of falling. In such situations, the speed governor, with its physical components, detects this state and triggers the safety clamp mechanism installed on the elevator car. This mechanism forces the elevator car to undergo emergency braking, ensuring the safety of passengers inside the car.
The Elevator Speed Governor is designed to meet the highest safety standards and is manufactured using advanced technology. Its reliable and precise detection system ensures prompt action in case of any speed-related emergencies, providing peace of mind to both passengers and building owners.
With its professional and robust construction, the Elevator Speed Governor is built to withstand the demands of continuous operation and harsh environments. It is easy to install and integrates seamlessly with existing elevator systems, making it an ideal choice for both new installations and modernization projects.
Choose the Elevator Speed Governor for its exceptional performance, reliability, and commitment to passenger safety. Trust in this vital component to provide the utmost protection for elevators, ensuring a smooth and secure ride for all users.
Regarding the LOG01 product, there are the following points to note
1:It's a Bi-Direction Overspeed Governor
2. Switch and solenoid Voltage: AC220V (optional DC24V).
3. Numbers of switch contacts: Single (optional Double).
| Model number |
No. |
Sheave Diameter
(mm) |
Rope Diameter
(mm) |
Rated Speed
(m/s) |
Tensile Force
T(N) |
Rope Tensile Force
F(N) |
Overall dimension
(A*B*C)(mm) |
Lifting Height
(m) |
Certifications |
| SN-SG-LOG01 |
A01 |
200 |
6 |
≤1.0/1.5/1.6/1.75 |
500-1800 |
280-550 |
236*114*315 |
≤90 |
GB/CE/EAC |
| A02 |
250 |
8 |
1.0/1.5/1.6/1.75/2.0 |
290*164*365 |
≤125 |
| A03 |
315 |
2.0/2.5 |
355*171.5*372.5 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
