Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution

Customer Reviews
Service is people-oriented and honesty is the most attractive. It's a pleasure to cooperate with you

—— Millay

I'm Online Chat Now

Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution

Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution
Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution

Large Image :  Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Elevator shaft magnetic
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $5~24
Packaging Details: Wooden box
Delivery Time: 7-15working days
Payment Terms: Western Union,T/T,L/C,Paypal
Supply Ability: 1000 Pcs/ Month

Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution

Description
Name: Elevator Shaft Magnetic Type: Elevator Parts
Packing: Standard Packing Product: Elevator Shaft Magnetic
Model: Elevator Shaft Magnetic Repeatability: ±1mm
Basic Gauge Length: 6.6mm Lift Height: Max 34m
Weight: ≈320g Power Supply Voltage: 10-30VDC

Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution

Elevator shaft magnetic absolute value information system

Applications

This product is used for absolute position detection of elevator cabins, achieving leveling without the need to encode floors or record floor numbers. The detection accuracy is higher, and the installation in the elevator shaft is not affected by environmental factors, making it simple to install and highly efficient.



4.4 Sensor Technology Data

Measurement Principle

Absolute Distance Measurement

Repeatability

±1mm

20System Accuracy at °C

±(2mm+0.1mm×L[m]); L = Measurement Length (m)

Basic Gauge Length

6.6mm

Sensor Housing Material

6061

Lift Height

Max 34m

Weight

320g

Power Supply Voltage

10-30VDC

Voltage Ripple

<200mVpp

Input Current

Max 0.1A

Interface

RS485/CAN

Resolution

0.1mm

Operating Speed

Max 4m/s

Storage Temperature

-30℃~100℃

Operating Temperature

-25℃~85℃

Humidity

95%RH (Max); No Condensation

Protection Level

IP54 (IP67 Customizable)


4.5 Magnetic Scale Technology Data

Model

AL-MS36 (1m~36m optional)

Gauge Length

6.6mm

Operating Temperature

-25℃~85℃

Storage Temperature

-30℃~100℃

External Magnetic Field Strength

<70mT (otherwise magnetic encoding will be damaged)

Precision at 20℃ (μm)

±(2mm+0.1mm×L[m]); L = Measurement Length

Carrier Material

12Cr17Ni7

Thermal Expansion

∆L[m]=L[m]×ɑ[1/K]×∆ ∂[K]

(L=Magnetic Scale Length (m), ∆ ∂=Relative Temperature Change)

Bending Radius

50mm (Min)

Usable Length

Max 36m

Magnetic Scale Weight

52g/m

Protection Level

IP65

Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution 0


Elevator Shaft Magnetic Brake System – High-Safety Emergency Stop Solution 1


FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.


Contact Details
SHANGHAI SUNNY ELEVATOR CO.,LTD

Contact Person: Mr. Wei CHEN

Tel: +86-13661864321

Fax: 86-021-59168286

Send your inquiry directly to us (0 / 3000)
