Progressive Elevator Safety Gear – EN 81 Certified Instantaneous Type Lift Safety Device For Elevators
Product Description:
Our Elevator Safety Gear, a reliable and essential component for ensuring utmost safety in elevator systems. Designed with precision and built to last, our Elevator Safety Clamp is the perfect solution for preventing any potential accidents or mishaps.
The Elevator Safety Gear comprises two main parts: linkage and the Safety Gear Body. This innovative design ensures that the elevator comes to an immediate halt in case of any emergencies or malfunctions, providing a fail-safe mechanism to protect both passengers and the elevator itself.
When the Safety Gear Mechanism is activated, it triggers the electrical switch, instantly disconnecting the elevator's safety circuit and bringing the elevator to a stop. In the rare event that the braking system fails to bring the elevator to a halt, the Safety Clamp takes further action, ensuring that the elevator is securely immobilized on the guide rails, preventing any potential risks.
With our Elevator Safety Gear, you can rest assured that the safety of your elevator passengers is our top priority. Our product complies with the highest safety standards and has undergone rigorous testing to ensure its reliability and effectiveness. Trust in our Elevator Safety Clamp to provide you with peace of mind and a secure elevator experience.
Invest in the best and make safety a priority with our Elevator Safety Gear. Don't compromise on the well-being of your passengers and the longevity of your elevator system.
Technical Specifications
| Certification |
Rated Speed (m/s) |
Max Load (P+Q) (kg) |
Guide Rail Width (mm) |
Tripping
Speed
(m/s) |
| GB/CE |
0.25 – 1.75 |
800 – 2600 |
9 / 10 |
0.29~2.33 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
