4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

Large Image : 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	SN-OCM-206

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	$500~1200
Packaging Details:	container
Delivery Time:	7~15 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	5000pcs/month

Contact Now

4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

Description

Name:	4-Leafs Center Opening Landing Door Device	Product Name:	4-Leafs Center Opening Landing Door Device
JJ:	600~1200MM	Used:	Elevator Parts
System:	Elevator Control System	Install:	Car Top Installation
Transportation:	Sea Delivery	Applicable:	Elevator Equipment
Model:	4-Leafs Center Opening Landing Door Device	Type:	4-Leafs Center Opening Landing Door Device
Highlight:	4-leafs elevator door operator , center opening elevator landing door , 600-1200mm elevator door device

4-Leafs Center Opening Landing Door Device For Home Lifts (Common Spring Type)

Product Specifications

Attribute	Value
Name	4-Leafs Center Opening Landing Door Device
Product Name	4-Leafs Center Opening Landing Door Device
JJ	600~1200MM
Used	Elevator Parts
System	Elevator control system
Install	Car top installation
Transportation	Sea Delivery
Applicable	Elevator Equipment
Model	4-Leafs Center Opening Landing Door Device
Type	4-Leafs Center Opening Landing Door Device

Product Features

Self-closing type: Using common spring self-closing type. Common spring is located inside the upper side of landing door device
Using door jamb unlocking type. 70 sill is applicable, especially for home lifts
Multiple certificates: Door lock qualified by the NATIONAL ELEVATOR INSPECTION CENTER. Level of protection is IP2
Standard floor height ≥ HH+600, lowest floor height HH+400
Door lock voltages ≤ AC230V,≤ DC110V

Technical Specifications

JJ	600	650	700	750	800	850	900	950	1000	1050	1100	1150	1200
A1L	1050	1100	1150	1200	1250	1325	1400	1475	1550	1625	1700	1775	1850
A2L	145	145	145	145	145	157.5	170	182.5	195	207.5	220	232.5	245
A	225	225	225	225	225	237.5	250	262.5	275	287.5	300	312.5	325
B	75	62.5	50	37.5	25	25	25	25	25	25	25	25	25
C	377.5	390	402.5	415	427.5	452.5	477.5	502.5	527.5	552.5	577.5	602.5	627.5

Product Images

Frequently Asked Questions

Are the elevator wire ropes durable?

The elevator wire rope has special provisions and requirements. Configuration considers not only wire rope and rated load, but also the size of the traction. The tensile strength of wire rope exceeds the weight of the lift, with a safety factor of at least four wire ropes to prevent simultaneous breakage.

Is it dangerous for power failure suddenly during the elevator running?

In case of power failure, the elevator will automatically stop due to electrical and mechanical safety devices. Elevator brakes will engage automatically. Power supply departments typically provide prior notice for planned outages.

Will us be hurt when it closed suddenly?

During closing, if the door contacts a person, it will automatically reopen without danger. The anti-pinch switch prevents closure when obstruction is detected, and closing force is carefully regulated.

How the elevator running?

Elevators operate via counterweight wire ropes through traction drive, moving vertically along guide rails.

Is the escalator installation complicated?

Our escalators feature integrated structures for precision and efficiency, making installation and commissioning simpler and more convenient.

Do you have any cerifications?

Yes, we hold ISO9001, CCC, and CE Certificates for our products.
