Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts

Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts
Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts
Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts

Large Image :  Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: car door operator
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts

Description
Name: Elevator Door Operator JJ: 700~1200mm
Used: Elevator Parts Model: Elevator Door Operator
Voltage: 220v To 250v 50/60 Hz Warranty Time: One Year
Open Type: Center Opening Opening Way: 2 Panels Centre Opening
Type: Elevator Door Operator
High Light:

Vvvf Car Elevator Door Operator

,

220v Elevator Door Operator

,

Straight Beam Mounting Elevator Door Operator

Vvvf Passenger Elevator Door Operator , Center Opening Elevator Door Components



Center opening VVVF door operator(Straight beam mounting)

The VVVF inverter control tech-nology
Synchronous belt drive, a slow, more stable and reliable operat- ion
Asynchronous door knife



JJ 700 750 800 850 900 950 1000 1050 1100 1150 1200
A1 1460 1560 1660 1760 1860 1960 2060 2160 2260 2360 2460
B1 225 250 275 300 325 350 375 400 425 450 475
C1 375 400 425 450 475 500 525 550 575 600 625



AS According to the straight beam inside the car frame size determination
EE According to the depth of the car 1/2 datermine
BB According to user requiements



Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts 0

Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts 1

Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts 2



Vvvf Car Elevator Door Operator 2 Panels Center Opening For Elevator Door Parts 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
