Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts

Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts
Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts
Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts

Large Image :  Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-DM-OL106
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts

Description
Name: Door Operator Door Opening: 600mm-1200mm
Voltage: AC220V Business Type: Manufacturer
Warranty Time: 12 Months Transportation: Sea Delivery
Applicable: Elevator Equipment Opening Way: Centre/Side Opening
Model: Door Operator Type: Door Operator
High Light:

Permanent Magnet Synchronous Elevator Door Operator

,

Center Opening Home Lift Door Operator

,

2 Leafs Elevator Landing Door Device



Product Characteristics

Using permanent magnet mator , wide torque range, high efficiency, environmental protection, energy savingThe synchronous belt drive directly, no slip,running smoothly in lower noise
The synchronous belt drive directly, running smoothly, more compact structureFull-closed-loop control technology, safe, reliable and easy to adjust
The door hanger has a safety hook to prevent collision and fall offAvailable options for 60 sill and 40 sill, especially for home lifts



SN-DM-OL106C(Car Top lnstallation)

2-Leafs Center Opening Permanent Magnet Synchronous Door OperatorFor Home Lifts (On Car Front-Wall lnstallation)

Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts 0



SN-DM-OL106A(On Car Front-Wall Installation)

2-Leafs Center Opening Permanent Magnet Synchronous Door OperatorFor Home Lifts (Car Top lnstallation)



Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts 1







JJ 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200
A1L 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 2400
A3L 175 200 225 250 275 300 325 350 375 400 425 450 475
B2L 890/1020 940/1070 990/1120 1040/1170 1090/1220 1140/1270 1190/1320 1240/1370 1290/1420 1340/1470 1390/1520 1440/1570 1490/1620



Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts 2



Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts 3



Center Opening Permanent Magnet Synchronous Door Operator 2 Leafs For Home Lifts 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
